Electrical Test Kits

This Reed Instruments electrical test kit includes the tools to troubleshoot common electrical problems. It includes a compact multimeter, AC voltage detector, receptacle tester, and carrying case to keep your instruments protected and organized..Electrical test kit containing tools to troubleshoot common electrical problem.Compact multimeter with built-in noncontact voltage detector measures AC/DC voltage and current, resistance, capacitance, frequency, diode, and continuity.Non-contact AC voltage detector with built-in flashlight suitable for outlets or against insulated wire.Receptacle tester in compact design that detects most common three-wire receptacle issues.Kit includes: multimeter with NCV, test leads, noncontact voltage detector, receptacle tester, carrying case, batteries

This Electrical Troubleshooting Kit includes a Circuit Breaker Finder/Receptacle Tester, Continuity Tester and AC Voltage Detector with built-in flashlight. All instruments and accessories in the R5500-KIT are conveniently stored and protected in a soft carrying case..Simply plug the transmitter into a receptacle and scan breaker box to identify the circuit.Detects 5 3-wire receptacle wiring faults.Built-in GFCI receptacle check function.Adjustable sensitivity wheel quickly identifies breaker.Audible (buzzer) and visual (LED) indicators assist in identification

This high voltage insulation tester is capable or testing voltages up to 5000V and measures insulation resistance up to 60GΩ. The R5002 performs a spot insulation test by applying a regulated and stabilized voltage to measure the amount of flowing current and then calculates resistance in order to evaluate insulation integrity..Test Voltages of 500V, 1000V, 2500V, and 5000V.Measure Insulation Resistance to 60GΩ.Large backlit LCD display with analog bargraph.Timer function for insulation resistance measurements (1-15min).AC/DC Voltage from 0 to 600V with Max/Min, peak and relative functions.Polarization index measurement (PI).Dielectric absorption ratio measurements (DAR).Max/Min, Peak, Relative value and Data Hold functions.Cat. IV 600V safety rating.Low battery indicator and auto shut off.7.8"H x 5.8"W x 3.4"D.Blue.Test voltages of 500V, 1000V, 2500V, 5000V DC.Accuracy of + or -5% rdg. +3 dgt..Resistance measurement range of 0.1 to 6000 ohm.Accuracy of + or -1.5% rdg. +10 dgt..Buzzer sounds at 50ohm for continuity test.Less than or equal to 200mA short circuit current.Includes test leads, batteries and a carrying case.High test voltages up to 5kV with insulation resistance to 60GΩ

The REED ST-5500 has many features such as 250V, 500V or 1000V test voltage combinations, a large, easy-to-read dual display with backlight and a durable double molded plastic housing making it stand up to the test of time..Insulation tester for test voltages of 250, 500 or 1000V.8" (h) x 3.5" (w) x 2" (d).Blue.1mA test current for Mohm range at rated voltage.200mA test current for continuity range.Continuity test with beeper.Large, easy-to-read dual display with backlight.Data hold switch.Test button may be locked on for hands-free operation.Double molded plastic housing.Meets IEC61010-1 Cat. III 1000V.Insulation Resistance Range of 200Mohm, 2000Mohm.Insulation Resistance Accuracy of + or -3.5% rdg. + or -5 dgt.Resistance Range of 200ohm, 2000ohm.Resistance Accuracy of + or -1% rdg. + or -2 dgt.Voltage Range of 750VAC / 1000VDC.Voltage Accuracy of AC: + or -1.2% rdg. + or -10 dgt and DC: + or -0.8% rdg. + or -3 dgt.Greater than or equal to 200mA Test Current.6 x 1.5V AA batteries for power supply.Includes test leads, battery and plastic carrying case

The R5500 instrument features a Circuit Breaker finder, a Circuit Tester and a GfCI Receptacle Tester. Quickly and easily identify the correct circuit breaker protecting a specific electrical circuit without service interruption..Simply plug the transmitter into a receptacle and scan breaker box to identify the circuit.Detects 5 3-wire receptacle wiring faults.Built-in GFCI receptacle check function.Adjustable sensitivity wheel quickly identifies breaker.Audible (buzzer) and visual (LED) indicators assist in identification.4" (h) x 2.2" (w) x 1.2" (d).Blue.Weighs 3.88oz.frequency range of 47 to 63Hz.Receiver is powered by a 9V battery (included).3-in-1 tester locates breakers, tests receptacles and GFCI circuits

The Fluke 325 True RMS Clamp Meter is a powerful, compact tool designed for professional electricians and technicians who require accurate electrical measurements in tight spaces. Ideal for both residential and commercial applications, this versatile meter measures AC/DC current up to 400 A, voltage up to 600 V, resistance, continuity, frequency, and even temperature, all with True RMS accuracy for reliable readings on non-linear loads. Its slim, ergonomic design allows for easy one-handed operation, while the large, backlit display ensures clear visibility in any environment. With built-in features like data hold, min/max recording, and a wide jaw opening that accommodates conductors up to 30 mm, the Fluke 325 is a dependable solution for diagnosing and troubleshooting electrical systems efficiently and safely..Electrical monitoring tool designed to measure current, voltage, resistance, continuity, frequency, and temperature..The Fluke 325 comes complete with TL75 test leads, a Type K thermocouple for temperature measurements, 2 pre-installed AAA batteries, and a soft carrying case for added portability and protection..The clamp meter measures approximately 8.15 inches in height, 2.95 inches in width, and 1.34 inches in depth (207 mm x 75 mm x 34 mm), offering a compact profile that fits easily in the hand or tool bag..The unit weighs approximately 0.62 pounds (283 grams), making it lightweight and convenient for extended use in the field..Suitable for both residential and commercial electrical environments.

This pocket-sized digital multimeter measures AC/DC voltage and current, resistance, frequency, capacitance and duty cycle. Designed to fit into the palm of your hand this compact DMM also includes diode test and continuity check functions..4.3"H x 2.3"W x 0.43"D.AC voltage range of 4, 40, 400, 600V.DC voltage range of 6400mV, 4, 40, 400, 600V.AC voltage accuracy of 4,40,400V + or -(1.2% rdg. + 3 dgt.) 600V + or -(1.5% rdg. + 5 dgt.).DC voltage accuracy of 400mV + or -(0.8% rdg. + 3 dgt.) 4,40,400V + or -(0.8% rdg. + 1 dgt.) 600V + or -(1% rdg. + 3 dgt.).AC voltage resolution of 1, 10, 100mV, 1V.DC voltage resolution of 0.1, 1, 10, 100mV, 1V.AC/DC current range of 400, 4000 A, 40, 400mA.AC current accuracy of 400/4000 A + or -(1.5% rdg. + 5 dgt.) 40/400mA + or -(2% rdg. + 5 dgt.).DC current accuracy of 400/4000 A + or -(1.0% rdg. + 3 dgt.) 40/400mA + or -(1.2% rdg. + 5 dgt.).AC/DC current resolution of 0.1, 1, 10, 100 A.Resistance range of 400ohm, 4, 40, 400kohm, 4, 40Mohm.Includes test leads, a battery and a carrying case.Auto ranging digital multimeter with 4,000 count LCD display

Discover the Fluke 177 True-RMS Digital Multimeter – Precision Meets Performance Experience precision and reliability like never before with the Fluke 177 True-RMS Digital Multimeter. Designed for the discerning electrical maintenance expert, this advanced multimeter is the perfect tool for troubleshooting and repairing a variety of electrical and electronic systems. With its ability to measure True-RMS AC and DC voltage and current, the Fluke 177 ensures accurate readings even in complex electrical environments. Its digital display, featuring an analog bar graph and backlight, provides clear and easy-to-read measurements, making your job easier even in dim lighting conditions. The Fluke 177 is built to last, crafted from durable chemical-resistant polymers, and housed in an ergonomic case with an integrated protective holster. This multimeter is designed to withstand the toughest conditions, ensuring longevity and reliability for years to come. Independently tested for safety, the Fluke 177 is rated for use in CAT IV 600V and CAT III 1000V environments, giving you the confidence to tackle high-voltage tasks. Its compact dimensions and lightweight design make it portable and easy to handle, while the 9V battery provides approximately 200 hours of typical use without the backlight. This multimeter is more than just a tool – it's a productivity enhancer. With features like manual and automatic ranging, Display Hold, Auto Hold, and Min/Max-average recording, you'll be able to work more efficiently and accurately. The Fluke 177 is part of the trusted Fluke 170 Series, renowned for its reliability and performance. When you choose the Fluke 177, you're investing in a tool that delivers unmatched accuracy and dependability. Upgrade your toolkit today with the Fluke 177 True-RMS Digital Multimeter and experience the precision and performance that professionals trust. Elevate your electrical maintenance capabilities and get the job done right every time..The Fluke 177 is a digital multimeter designed for precise measurement of electrical and electronic systems, providing True-RMS readings for AC/DC voltage and current, as well as frequency, capacitance, resistance, continuity, and diode testing..This comprehensive kit comes with the Fluke 177 Digital Multimeter, one pair of test leads with 4mm lantern tips, an installed 9V battery for immediate use, and a quick reference guide to help you get started quickly and efficiently..The Fluke 177 Digital Multimeter is compact and portable, with dimensions of 43 mm in depth, 90 mm in width, and 185 mm in height, making it a convenient tool to carry and use in various environments..Weighing just 420 grams (14.82 ounces), the Fluke 177 Digital Multimeter is lightweight yet robust, ensuring ease of use and transport without compromising on durability or performance.

This auto ranging multimeter is IP67 rated, has a 40,000 count display for precise readings and is capable of measuring AC/DC voltage and current, frequency, resistance, capacitance and temperature. This DMM also includes diode and continuity tests and features 4-20 mA loop measurement and a digital analog bargraph..True RMS AC/DC voltage and current measurements.Measures frequency, resistance, capacitance and temperature.Diode check and continuity functions.Backlit LCD readout with analog bar graph.4-20 mA process loop measurements with % readout.Data hold, Max/Min and Peak capture mode.IP67 dust and waterproof.Cat. IV 600V, Cat. III 1000V safety rating.7.4"H x 3.2"W x 2.0"D.AC range of 400mV, 4, 40, 400, 1000V.DC range of 400mV, 4, 40, 400, 1000V.AC accuracy of + or -(1.0% rdg. + 5 dgt.) at 400mV and + or -(1.0% rdg. + 3 dgt.) for other ranges.DC accuracy of + or -(0.1% rdg. + 5 dgt.) at 1000V and + or -(0.06% rdg. + 2 dgt.) for other ranges.AC resolution of 0.1mV, 0.001, 0.01, 1V.DC resolution of 0.01mV, 0.0001, 0.01, 0.1V.AC/DC current range of 400, 4000 A, 40, 400mA, 10A.AC current accuracy of + or -(1.5% rdg. + 3 dgt.).DC current accuracy of + or -(1.0% rdg. + 3 dgt.).Temperature range of -58 to 1832degree f (-50 to 1000degree C).True RMS multimeter with built-in non-contact voltage detector and 40,000 count backlit LCD display

This compact autoranging clamp meter is capable of measuring AC current, AC/DC voltage, resistance, frequency, capacitance, duty cycle and temperature. Featuring double molded plastic housing, the R5020 includes diode check and continuity functions and a non-contact voltage detector built into the clamp tip..Measures AC current, AC/ DC voltage, resistance, capacitance, frequency, duty cycle and temperature.4000-count LCD display with low battery and over range indicators.Built-in non-contact voltage detector with LED indicator.Display hold and relative mode.Diode test and continuity check functions.Durable double molded plastic housing.Cat. III 600V safety rating.7.9"H x 2.6"W x 1.5"D.Blue.AC current range of 40, 400A.AC accuracy of + or -(2.5% rdg. + 8 dgt.).AC resolution of 0.01, 0.1A.AC voltage range of 4, 40, 400, 600V.DC voltage range of 400mV, 4, 40, 400, 600V.AC voltage accuracy of + or -(1.8% rdg. + 8 dgt.).DC voltage accuracy of + or -(1.5% rdg. + 2 dgt.).AC voltage resolution of 0.001, 0.01, 0.1, 1V.DC voltage resolution of 0.1mV, 0.001, 0.01, 0.1, 1V.Resistance range of 400ohm, 4, 40, 400kohm, 4, 40Mohm.Includes test leads, a thermocouple wire probe, a thermocouple adapter, batteries and a soft carrying case.Compact AC clamp meter with built-in non-contact voltage detector and contact thermometer

This compact autoranging True RMS clamp meter is capable of measuring AC/DC current and voltage, resistance, frequency, capacitance, duty cycle and temperature. Featuring a 50,000 count backlit LCD display, double molded plastic housing, the R5030 includes diode check and continuity functions and a non-contact voltage detector built into the clamp tip..Measures AC/DC current/voltage, resistance, capacitance, frequency, duty cycle and temperature.50000-count backlit LCD display with low battery and overrange indicators.Built-in non-contact voltage detector with LED indicator.True RMS AC measurements.Display hold and relative mode.Diode test and continuity check functions.Durable double molded plastic housing.Cat. III 600V safety rating.7.9" (h) x 2.6" (w) x 1.5" (d).AC/DC current range of 50.00, 500.0A.AC current accuracy of + or -(2.8% rdg. +30 dgt.).DC current accuracy of + or -(2.5% rdg. +30 dgt.).AC/DC current resolution of 0.01, 0.1, 1A.AC voltage range of 500mV, 5, 50, 500, 750V.DC voltage range of 500mV, 5, 50, 500, 1000V.AC voltage accuracy of + or -(1.0% rdg. +30 dgt.).DC voltage accuracy of + or -(0.1% rdg. +4 dgt.).AC/DC voltage resolution of 0.1mV, 0.001, 0.01, 0.1, 1V.Includes test leads, a thermocouple wire probe, a thermocouple adapter, batteries and a soft carrying case.Compact AC/DC clamp meter with backlit display, built-in non-contact voltage detector and contact thermometer

This versatile Reed Instruments compact-sized multimeter measures AC/DC voltage and current, resistance, capacitance, frequency, diode, and continuity. It also features a built-in non-contact voltage detector to quickly detect live voltage on electrical circuits found in residential, commercial, and industrial buildings..Multimeter to measure AC/DC voltage and current, resistance, capacitance, frequency, diode, and continuity.Built-in non-contact voltage detector and double-molded plastic housing.4000-count backlit LCD display.Low battery indicator and auto shutoff.CAT III 600V safety rating

This auto ranging multimeter is capable of measuring AC/DC voltage and current, resistance, frequency, capacitance and temperature. Featuring double molded plastic housing, the R5008 includes diode check and continuity functions and ships complete with test leads and a thermocouple probe for contact temperature measurements..Measures AC/DC voltage and current, frequency, resistance, capacitance and temperature.Diode check and continuity functions.Relative and data hold functions.Double molded plastic housing.Cat. III 600V safety rating.5.9"H x 2.8"W x 1.9"D.AC voltage range of 400mV, 4, 40, 400, 600V.DC voltage range of 400mV, 4, 40, 400, 600V.AC voltage resolution of 0.1mV, 1, 10, 100V.DC voltage resolution of 0.1mV, 1, 10, 100V.AC/DC current range of 400, 4000 A, 40, 400mA, 10A.AC/DC current resolution of 0.1, 1 A, 10, 100mA, 1A.Resistance range of 400ohm, 4, 40, 400kohm, 4, 40Mohm.Resistance resolution of 0.01ohm, 1, 10, 100kohm, 1, 10Mohm.Includes a temperature input adapter, type K thermocouple wire probe, test leads, a battery and a carrying case.Compact auto ranging digital multimeter with 11 functions

This Industrial Combo Kit includes the tools required for your plant maintenance needs. The RINDUST-KIT includes a Multimeter, Clamp Meter, AC Voltage Detector, Infrared Thermometer and Hard Carrying Case. The carrying case features a customized foam insert built specifically to store and protect the included instruments..R5010- True RMS multimeter with built-in non-contact voltage detector and 40,000 count backlit LCD display..R5020- Compact AC clamp meter with built-in non-contact voltage detector and contact thermometer.R2002- Pocket-sized infrared thermometer with backlit display and fixed emissivity will cover 90% of non-contact temperature applications..R5100- Non-Contact AC Voltage Detector with Flashlight.AD-1- This adapter converts any Type-K thermocouple temperature probe with a mini-connector to dual shrouded banana plug inputs..TP-01- Beaded Thermocouple Wire Probe, Type K, -40 to 482°F (-40 to 250°C).TL-88-1- Safety Test Lead Set, Double Insulated.R8890- Professional grade, injection molded hard plastic case with customizable foam inserts.
