RS-232 Serial Adapter

The UDS1100 Device Server with PoE enables users to connect, manage and control just about any piece of equipment with a serial port from virtually anywhere over Ethernet or the Internet..Ports: 1 x RJ 45, 1 x DB 25.Dimensions: 3 1/2"(H) x 2 1/2"(W) x 0.9"(D).Compatibility: PC.Form factor: Wall mountable, Processor speed: 48 MHz.Ethernet technology: Fast ethernet, Data link protocol: Ethernet, fast ethernet, RS 232, RS 422, RS 485.Interface/ports: 1 x serial - RS 232/422/485 - 25 pin D Sub (DB 25), 1 x network / power - Ethernet 10base T/100Base TX - RJ 45.Connectivity technology: Wired.Status indicators: Link activity, power, status.Standard memory: 256 KB, Memory technology: SRAM, Flash Memory installed (Max): 2 MB.Operating temperature: 41 - 122 deg F.Input voltage: 30 VDC.Software selectable RS232, RS422 or RS485, flow control, DHCP support, ARP support, half duplex mode, full duplex mode.Network protocols: TCP/IP, UDP/IP, ICMP/IP, Remote management protocol: SNMP, Telnet, HTTP.Certificate and standards: IEEE 802.3, IEEE 802.3u, IEEE 802.3af, UL, CSA, FCC, CE, TUV, C Tick, C Tick.Weight: 7.05 oz..Warranty: 2 years limited.Latronix Device Server with PoE - Simplicity and Speed

The Lantronix® XPress™ DR-IAP industrial device server with 10/100Base-TX Fast Ethernet connectivity, allows you to connect, manage and control any equipment with a serial port from nearly anywhere through a network or the Internet. The installable industrial protocols support various communication drivers. It has one RJ-45 network port and one RS-232/422/485 serial network port for enhanced connectivity. This device server is a quick, simple and inexpensive way of adding Ethernet connectivity to virtually any device with a serial interface..Industrial device server with installable industrial protocols allow virtually any serial device to connect to a new or existing Ethernet network.Dimensions: 3.54"H x 1.4"W x 2.4"D.High-impact plastic for durability.Media type supported: Twisted pair.Connectivity: 10/100Base-TX Fast Ethernet, Data rates: 300 - 115200 bps, Characters: 7 or 8 data bits.Interfaces/ports: Network (RJ-45), RS-232/422/485 serial.Form factor: DIN rail-mountable.Connector type: Terminal block (screw).Power supply: 9 - 24 VAC/9 - 30 VDC, Power consumption: 3 W (operational).Network transport protocol: ARP, BOOTP, DHCP, ICMP/IP, TCP/IP and UDP/IP.Remote management protocol: HTTP, SNMP, Telnet and TFTP.Status indicators: Active, fail, link ok, ready, receive and transmit.Operating system: Microsoft Windows.Meets UL, CSA, CE, RCM, VCCI and RoHS certifications and standards.Comes with 1 year limited warranty
