NETGEAR SFP Modules

Supports optical fiber cable for durable performance, minimal signal loss, and fast data transfers to greater distances.With a single wavelength of light, the single mode fiber optic can carry data and transmit audio/video applications over miles of distance.Gigabit Ethernet port for ultra-fast network speeds.With 1000Base-LX technology, enjoy up to 1000Mbps data transfer rate over optical fiber cable

The Cisco 10GBASE-SR module supports link lengths up to 26m on standard Fiber Distributed Data Interface (FDDI) grade multimode fiber (MMF). Using 2000MHz x km of MMF (OM3), it is possible to create link lengths up to 300m, and with 4700MHz x km MMF (OM4), link lengths up to 400m are possible..Multimode fiber optic transceiver with dual LC/PC connector.10GBASE SFP+ module for data center, enterprise wiring closet, and service provider transport applications.Provides data transfer rates up to 10Gbps.Supports link lengths up to 26m on standard FDDI-grade MMF; up to 300m on 2000MHz x km MMF (OM3); and up to 400m on 4700MHz x km MMF (OM4).Power consumption: 1W.Hot-swappable, plugs into an Ethernet SFP+ port.Compliant with the SFP+ MSA SFF-8431 standard.Wavelength: 850nm.Form factor: Hot-swappable.MSA compliant.Commercial temperature: 32 to 158 degrees Fahrenheit.Supports digital optical monitoring capability.Optical interoperability with 10GBASE XENPAK, 10GBASE X2, and 10GBASE XFP interfaces on the same link.1-year manufacturer limited warranty

The Cisco 10GBASE-SR module supports link lengths up to 26m on standard Fiber Distributed Data Interface (FDDI) grade multimode fiber (MMF). Using 2000MHz x km of MMF (OM3), it is possible to create link lengths up to 300m, and with 4700MHz x km MMF (OM4), link lengths up to 400m are possible..Multimode fiber optic transceiver with dual LC/PC connector.10GBASE SFP+ module for data center, enterprise wiring closet, and service provider transport applications.Provides data transfer rates up to 10Gbps.Supports link lengths up to 26m on standard FDDI-grade MMF; up to 300m on 2000MHz x km MMF (OM3); and up to 400m on 4700MHz x km MMF (OM4).Power consumption: 1W.Hot-swappable, plugs into an Ethernet SFP+ port.Compliant with the SFP+ MSA SFF-8431 standard.Wavelength: 850nm.Form factor: Hot-swappable.MSA compliant.Commercial temperature: 32 to 158 degrees Fahrenheit.Supports digital optical monitoring capability.Optical interoperability with 10GBASE XENPAK, 10GBASE X2, and 10GBASE XFP interfaces on the same link.1-year manufacturer limited warranty

The SGFEB provides a cost effective method for integrating 1000Base-SX/LX fiber into a 10/100/1000Base-T copper environment. Deploying fiber into today's networks provides the ability to transmit data over significantly longer distances than is possible on copper. Fiber also protects your data from external sources of noise and interference, improving network performance..Meet the multiple network connectivity needs of today's network environment with this 2 transceiver/media converter.Supports optical fiber cable for durable performance, minimal signal loss, and fast data transfers to greater distances.With 10/100/1000Base-T technology get up to 1000Mbps data transfer rate over optical fiber cable

The Transition Networks® TN-GLC-SX-MM 1000Base-SX Gigabit Ethernet SFP transceiver module is suitable for Gigabit Ethernet switches and routers, fiber channel switch infrastructure, xDSL applications and metro edge switching. This hot pluggable transceiver module with LLC 1000Base-SX interface, transfers data at the rate of 1.25 Gbps up to 550 m distance over multi-mode fiber media at a wavelength of 850 nm. This transceiver module helps to install in any SFP port allowing for 1000Base-SX interface to the network through the SFP connector..Hot-pluggable SFP transceiver module is suitable for Gigabit Ethernet switches, routers, fiber channel switch infrastructure and xDSL applications.Dimensions: 0.33"H x 0.52"W x 2.18"D.Supports multi-mode fiber (MMF) connection media.Interfaces/ports: One LC 1000Base-SX.Ethernet technology: Gigabit Ethernet.Maximum data transfer rate: 1.25 Gbps.Reach: 550 m.Wavelength: 850 nm.Media type supported: Optical fiber.Link budget: 8.5 dB.Power: 3.3 V, Power consumption: 0.66 W.Temperature range: 0 - 70 deg C operating, 40 - 85 deg C storage.Fiber optic cable standard: 62.5/125 u m, 50/125 u m.SFP footprint LC optical transceiver.Has been designed to install in any SFP port while allowing for 1000Base-SX interface to the network through the SFP connector.Meets MSA, IEC-60825, FDA 21, CFR 1040.10 and 1040.11, IEEE 802.3 2003, ANSI X3.297-1977 certifications and standards.Comes with lifetime warranty

The Cisco SFP-10G-SR module is the multimode 10G fiber optical transceiver, and it supports up to 400m link length when uses 4700Mhz KM MMF (OM3). The 10GBase-SR SFP+ module offer customers a wide variety of 10 gigabit Ethernet connectivity options for data center, enterprise wiring closet, and service provider transport applications..Cisco SFP-10G-SR module is the multimode 10G fiber optical transceiver.Industry’s smallest 10G form factor for greatest density per chassis.Compatibility: Cisco nexus 5000 series Switches, cisco nexus 7000 series switches.Hot Pluggable.850nm VCSEL transmitter, PIN photo-detector.Maximum link length of 300m on 2000MHz/km MMF.Operating case temperature: 0 to 70 °C.Additional information: Spare product, distance 300 m.Form factor: Plug-in module.Application/usage: Data networking.90 days limited warranty.The Cisco SFP-10G-SR module is the multimode 10G fiber optical transceiver. SFP+ transceiver module supports a link length of 26 m on standard fiber distributed data interface (FDDI)-grade multimode fiber (MMF).

Industry standard Cisco small form factor pluggable (SFP) gigabit interface converter is a hot-swappable input/output device that plugs into a gigabit Ethernet port or slot, linking the port with the network..Interfaces/ports: 1 x LC duplex 1000Base-LX/LH.Dimensions: 0.3"(H) x 1/2"(W) x 2.2"(D).Compatibility: Cisco IE 3000 series switches, cisco 3200 series rugged routers, cisco MWR 2900 mobile wireless routers.Connectivity technology: Wired.Connectivity media: Single mode fiber 1000Base-LX/LH.Operating temperature: -40 - 185 deg F.Fiber type: SMF/MMF.Cabling type: Ethernet 1000Base-LX.Additional information: Spare product, range: 10 Km, wavelength: 1300 nm.Data transfer rate: 1 Gb/s gigabit Ethernet.Form factor: Hot swappable/plug-in.Application/usage: Data networking.SFP (mini-GBIC) transceiver module 1000 MBPS SFP single mode rugged 1000BASE-LX/LH SFP for MMF and SMF.

Our Compatible WatchGuard WG8583 SFP+ transceiver is based on our 10G-SFP-300 product, which has the same parameters and is manufactured in accordance with the same industry standards as its OEM counterpart. Our compatible module version is designed for operation over a Double Fiber Multi-Mode Fiber (MMF) optical cable. It has a minimum guaranteed optical budget of 4.6 dB, which typically is enough to reach about 300 meters over OM3 type fiber or 400 meters over OM4 or higher MMF category fiber. However, distance is only an indicative parameter calculated for identification comfort. Finally, we calculate distance while keeping in mind the minimum (guaranteed) optical budget and the average attenuation of optical cabling in the industry. Our WatchGuard WG8583 compatible transceiver uses a high-quality VSCEL Laser transmitter operating at 850 nm nominal wavelength and a 850 nm PIN Photodiode receiver..WatchGuard WG8583 transceiver module is a Multi-Mode Fiber (MMF) & LC Duplex Connector..Its a 10GBASE-SR SFP+ Transceiver Module for 10-Gigabit Ethernet connectivity..Data Transfer Rate for this module is 10,312.5 Mbps (10.3125 Gbps) and 10,312,500 Kbps..Maximum Distance covered by this module is 300 meters.It supports 10-Gigabit Ethernet..The WatchGuard WG8583 has a power consumption of approximately 1.0 watts.It is a hot swappable module..the WatchGuard WG8583 is MSA compliant.The WatchGuard WG8583 has a Mean Time Between Failures (MTBF) of approximately 1,155,348 hours.This transceiver module operates at a wavelength of 850 nm

The Cisco SFP-10G-SR module is the multimode 10G fiber optical transceiver, and it supports up to 400m link length when uses 4700Mhz KM MMF (OM3). The 10GBase-SR SFP+ module offer customers a wide variety of 10 gigabit Ethernet connectivity options for data center, enterprise wiring closet, and service provider transport applications..Cisco SFP-10G-SR module is the multimode 10G fiber optical transceiver.Industry’s smallest 10G form factor for greatest density per chassis.Compatibility: Cisco nexus 5000 series Switches, cisco nexus 7000 series switches.Hot Pluggable.850nm VCSEL transmitter, PIN photo-detector.Maximum link length of 300m on 2000MHz/km MMF.Operating case temperature: 0 to 70 °C.Additional information: Spare product, distance 300 m.Form factor: Plug-in module.Application/usage: Data networking.90 days limited warranty.The Cisco SFP-10G-SR module is the multimode 10G fiber optical transceiver. SFP+ transceiver module supports a link length of 26 m on standard fiber distributed data interface (FDDI)-grade multimode fiber (MMF).

The Axiom SFP-10G-SR-AX SFP+ transceiver module supports fiber network connectivity using MMF. The transceiver transfers the data over this MMF at 10GBASE-SR data rate, with a maximum reach of up to 300 m using OM3 and up to 400 m using OM4, at 850 nm wavelength. The transceiver comes with pre-configured specific code to meet the requirements set forth by your router and switch OEMs. This SFP transceiver module is compatible with Cisco Catalyst 2960-S/2960-X/3560-X/3750-X series and Nexus 5000/7000 series..SFP+ transceiver transfers the data over multi-mode fiber.Dimensions: 0.5"H x 0.5"W x 2.2"D.Compatible with Cisco Catalyst 2960-S/2960-X/3560-X/3750-X series, Nexus 5000/7000 series.Network technology: 10GBASE-SR.Interfaces/Ports: 1 x LC.Wavelength: 850 nm.Range: 300 m using OM3 and up to 400 m using OM4.Ethernet technology: 10 Gigabit Ethernet.Media type supported: Multi-mode optical fiber.Form factor: Plug-in module.Eliminates any network communication conflicts and provides easy identification.Fully comply with the multi-sourcing agreement (MSA) which enables them to work in all MSA compliant platforms.Meets SFP+ MSA, RoHS, IEEE 802.3z standards.Comes with limited lifetime warranty

To ensure that specifications are met over FDDI-grade, OM1 and OM2 fibers, the transmitter should be coupled through a mode conditioning patch cord. No mode conditioning patch cord is required for applications over OM3..SFP+ module is perfect for data networking, optical network.Dimensions: 0.3"H x 0.5"W x 2.2"D.Compatible with A9K-16T/8-B=, ME-3600X-24FS-M=, ME-3600X-24TS-M, N7K-F132XP-15=, N7K-M132XP-12L, WS-X45-SUP7-E/2 networking products.Interface/ports: 1 x LC duplex 10GBase-LRM network.Media type supported: Optical fiber, fiber mode supported: Multi-mode, single-mode, Ethernet technology: 10 Gigabit Ethernet.Maximum data transfer rate: 10 Gbps.Form factor: Hot-swappable, plug-in module.Up to 980', fiber optic cable standard: 62.5 ohm m, 50 ohm m, wavelength: 1300nm.Supports link lengths of 220m on standard fiber distributed data interface (FDDI) grade multimode fiber (MMF).Temperature range: 32 - 158 deg F.Transmit power: -6.5 to 0.5 dBm.Receive power: -8.4(in average) and -6.4 (in OMA) - 0.5 dBm.Connectivity media: 62.5 um, 50 um multi-mode fiber 10GBase-LRM, single-mode fiber 10GBase-LRM.Power consumption: 1 W.Core size: 62.5 - G.652 microns.Cable distance: 220 - 300 m.Cable type: MMF and SMF.Transmit and receive wave length: 1260 - 1355nm.Compliant standards: IEEE 802.3ae, IEC 60825-1, laser class 1.Warranty: 90 days limited.10GBase-LRM SFP transceiver module supports link lengths of 220 m on standard fiber distributed data interface (FDDI) grade multimode fiber (MMF).

The Opengear 569023 1000Base-SX Optical Fiber SFP Transceiver module for data networking, transfers data at the rate of 128 MBps. The module in silver color, has 1000Base-SX network interface for better connectivity..SFP transceiver module for data networking.Color: Silver.Interfaces/ports: One 1000Base-SX network.Data transfer rate: 128 MBps.Transfer distance: 1804.46'

If your current port density doesn't quite meet your needs, upgrade your system with the Juniper SFP-1GE-SX SFP module. This hot-pluggable piece boasts a wavelength that extends anywhere from 830 nm to 860 nm and has an impressive launch power that typica.1 x 1000Base-SX.Optical interface: Multi-mode.Interface: 1 x SFP.Data transfer rate: 1000 Mbps.Form factor: Plug-in module.Network technology: 1000Base-SX Gigabit Ethernet.Average launch power: -9.5 through 0 dBm, Average receive power: -17 through 0 dBm.Maximum distance: 62.5/125 MMF cable: 656', 50/125 MMF cable: 1640'.Transmitter wavelength: 770 through 860 nm.Receiver sensitivity: -17 dBm.500 m reach on 50/125 micrometer MMF.Wavelength: 830 to 860 nm.SNMP: V 1.Average launch power: -9.5 to -4 dBm.Receiver saturation: -3 dBm.Form factor: Small.Juniper SFP-1GE-SX Gigabit Ethernet SFP Module - Wired Connection

ACP's industry-standard 10Gbase-SR SFP+ is a hot-swappable input/output device that plugs into a gigabit Ethernet slot, linking the port with the fiber-optic network..Interfaces/ports: 1 x 10GBase-SR, 1 x LC/PC duplex 10GBase-SR network.Dimensions: 0.3"(H) x 1/2"(W) x 2.2"(D).Compatibility: Cisco Nexus 5000 series, 7000 series switches.Connectivity technology: Wired.Connectivity media: 62.5 um, 50 um multi mode fiber 10GBase-SR.Humidity: 0% - 95%.Operating temperature: 32 -158 deg F.Enclosure type: Plug-in module.Data transfer rate: 10 Gb/s gigabit Ethernet.Form factor: Hot-swappable.Application/usage: Data networking.3 years limited warranty.Transceiver module compatible 10GBase-SR SFP+ sub watt power consumption and its excellent EMI performance allow system design with high port density.

WatchGuard WG9020 Firebox M-Series 2-Port 10GbE SFP+ Expansion Module The WatchGuard Firebox M-Series 2-Port 10-Gigabit SFP+ Expansion Module allows you to add more interfaces to your M-Series Firebox appliance (sold separately). It is easily installed in the interface slot on your 3rd Gen Firebox (see specifications tab for compatibility)..WG9020 module have Single Mode for Fiber cable and LC (Lucent Connector) is for fiber connector..Network Transceiver is SFP+ Transceiver Module Used for 10 Gigabit Ethernet connectivity..The WG9020 module supports a data transfer rate of up to 10 Gbps, (10,000 Mbps), 10,000,000 Kbps (Kilobits per second) over optical fiber..This module supports a maximum distance of up to 10,000 meters when using single-mode fiber..The WG9020 module Supports 10 Gigabit Ethernet.Power Consumption for this module is 2.5 watts..This module is msa compliant..It supports MTBF 1,000,000 hours..The WG9020 module operates at a wavelength of 1310 nm.

The Opengear 1000Base-LX/LH mini-GBIC SFP transceiver module operates at 1 Gbps and offers optical links up to 10 km long via single-mode fiber cable at a wavelength of 1310 nm. It is compatible with IM7200 infrastructure manager for data networking..SFP transceiver module for data networking, optical network and compatible with IM7200 infrastructure manager.Interfaces/ports: One 1000Base-LX/LH network.Ethernet technology: Gigabit Ethernet, Maximum data transfer rate: 1 Gbps, Max transfer distance: 10 km, Optical wave length: 1310 nm.Media type supported: Optical fiber, Fiber mode supported: Single-mode
