Fiber SFP Modules

The Cisco multi-mode rugged SFP module adapts your switch or router, enabling you to connect long-range cables. As a result, you can extend the range of your network and expand connectivity. The SFP module is made with an intuitive design that is easy to install and use, so you can expand your network quickly and with minimum hassle..Interfaces/ports: 1 x LC duplex 100Base-FX.Dimensions: 0.33"(H) x 0.52"(W) x 2.22"(D).Compatibility: Cisco 100 m Ethernet SFP Compatibility matrix.Connectivity technology: Wired.Optical wave length: 1310 nm.Temperature: 122 deg F max operating.Compliant standards: IEEE 802.3, IEEE 802.3ah.Connectivity media: Multi mode fiber 100Base-FX.Max transfer distance: 1.2 miles.Data transfer rate: 100 Mbps fast ethernet.Form factor: Hot-swappable.90 days limited warranty.Cisco Multi-Mode Rugged SFP Module - Hot-Swap Capability

If your current port density doesn't quite meet your needs, upgrade your system with the Juniper SFP-1GE-SX SFP module. This hot-pluggable piece boasts a wavelength that extends anywhere from 830 nm to 860 nm and has an impressive launch power that typica.1 x 1000Base-SX.Optical interface: Multi-mode.Interface: 1 x SFP.Data transfer rate: 1000 Mbps.Form factor: Plug-in module.Network technology: 1000Base-SX Gigabit Ethernet.Average launch power: -9.5 through 0 dBm, Average receive power: -17 through 0 dBm.Maximum distance: 62.5/125 MMF cable: 656', 50/125 MMF cable: 1640'.Transmitter wavelength: 770 through 860 nm.Receiver sensitivity: -17 dBm.500 m reach on 50/125 micrometer MMF.Wavelength: 830 to 860 nm.SNMP: V 1.Average launch power: -9.5 to -4 dBm.Receiver saturation: -3 dBm.Form factor: Small.Juniper SFP-1GE-SX Gigabit Ethernet SFP Module - Wired Connection

Cisco™ 1000BASE-EX SFP Transceiver module is hot-swappable and supports a 1310 nm wavelength signaling. Module operates on standard SMF optic link that spans up to a distance of 40 km..Interface/ports details: 1 x 1000Base-EX network.Media and performance: G.652 micrometer single mode optical fiber.Ethernet technology: 1 Gbps gigabit ethernet.Dimensions: 0.3"(H) x 0.5"(W) x 2.2"(D).Application/usage: Data networking.Form factor: Hot swappable.Wavelength: 1310-nm, Reach: 40 km.Compatibility: Cisco ME 3400 series ethernet access switches, Cisco catalyst 3750 metro series switches.Weight: 2.65 oz..Warranty: 90 days limited.Cisco™ 1000BASE-EX SFP Transceiver module is designed to connect a gigabit ethernet port to a network and has dual LC/PC single mode connectors.

Supports optical fiber cable for durable performance, minimal signal loss, and fast data transfers to greater distances.With its thicker diameter to carry the light of multiple wavelengths, multi-mode fiber optic cable supports the high bandwidth to carry more information with greater fidelity.Optimize the network's performance with 10 Gigabit Ethernet connectivity.With 10GBase-SR technology, enjoy up to 10Gbps data transfer rate over optical fiber cable

The NETGEAR AGM731F fiber 1000BASE-SX SFP GBIC module expands the capabilities of your existing switch, enabling it to accept fiber-optic connections. The module is compact in size and plugs in easily, so you can upgrade your system in less than a minute. It features a single port, so you can extend network coverage across a larger area..Interfaces/ports: 1 x LC 1000Base-SX LAN.Dimensions: 0.4"(H) x 1/2"(W) x 2.6"(D).Compatibility: Adds fiber optic connectivity to the GSM7324, meets SFP GBIC standard for use with any SFP GBIC compliant slot 1000BASE-SX connectivity.Connectivity technology: Wired.Connectivity media: 62.5 um multi mode fiber 1000Base-SX, 50 um 1000Base-SX.Operating temperature: 32 - 104 deg F.Humidity: 10 - 90%.MTBF: 5,083,574 hours.Module support: Mini-GBIC, SFP.Data transfer rate: 1 Gb/s.Performance class: Gigabit ethernet.Form factor: Plug-in module.Application/usage: Data networking.Expansion slots: 4 (total)/4 (free) x SFP (mini-GBIC).5 years limited warranty.NETGEAR AGM731F Fiber 1000BASE-SX SFP GBIC Module - High-Speed Connections

Cisco 100BASE-FX small form-factor pluggable (SFP) fast Ethernet interface converter is a hot-swappable device that plugs into a gigabit Ethernet SFP port on Cisco catalyst 3750 series, 3560 series, and 2970 series switches..Interfaces/ports: 1 x LC duplex 100Base-FX.Dimensions: 0.4"(H) x 2.2"(W) x 1/2"(D).Compatibility: Cisco catalyst 3750, 3560, and 2970 series switches.Connectivity media: 62.5/125 um multi mode fiber, 50/125 um multi mode fiber.Transmit (dBm): 50/125-micron: -23.5 min, -14max, 62.5/125-micron: -20 min, -14max, receive (dBm): 50/125-micron: -33.35 min, -11.8 max, 62.5/125-micron: -33.35 min, -11.8 max.Distance supported: 6.5'.Operating temperature: 32 - 158 deg F, storage temperature: -40 - 185 deg F.Surge current: 350 typical, wavelength (nm): 1270 min, 1300 typical, 1380 max.Power consumption: 1.5 W per port.Input voltage: 3.3 V - 3.5 V device, 3.3 V typical device.Input current: 405 mA typical, 450 mA maximum.Data transfer rate: 100 Mbps fast Ethernet full duplex.MTBF: 12,820,512 hours.Form factor: Hot-swappable.System requirements: Cisco IOS software release 12.2(20)SE1.Application/usage: Data networking.Regulatory and standards compliance: IEC 60825-1.SFP fast ethernet interface converter 100FX SFP on GE SFP ports for DSBU switches.

Transition Networks® Cisco compatible SFP transceiver module features 1000Base-LX interfacing through SFP connector and are designed for bidirectional serial-optical data communication. Module used in gigabit ethernet operate at a speed of 1.25 Gbps..Interfaces/ports: 1 x 1000Base-LX, Interfaces/ports details: 1 x LC 1000Base-LX.Dimensions: 0.3"(H) x 0.5"(W) x 2.2"(D).Compatible with: 1000BLX SM LC 10KM 3.3V.Application/usage: data networking.Warranty: lifetime.Transition Networks® Single mode SFP transceiver module are Cisco compatible allowing 1000Base-LX interface to the network and operates at 1310nm wavelength there by finding its application in gigabit ethernet, metro edge switching.

AddOn® SFP+ Module can be mixed with 3rd party transceivers for outstanding network performance. Module operates at 1310 nm over multi-mode fiber with a maximum reach of 220 m connected through a LC connector..Interface/ports: 1 x LC duplex 10GBase-LRM network.Dimensions: 0.3"(H) x 0.5"(W) x 2.2"(D).Compatibility: Catalyst 2360, catalyst 3100 blade switches, Nexus 7000, catalyst 2960-S, catalyst 3560-E, catalyst 3560-X, catalyst 3750-E. catalyst 3750-X, catalyst 4500, catalyst 4900, ME 4900, catalyst 6500.Connectivity technology: Wired.Form factor: Hot-swappable.Connectivity media: Multi-mode optical fiber 10GBase-LRM.Max transfer distance: 720 ft.Data transfer rate: 10.30 Gbps gigabit Ethernet.1310nm.Environmental condition: Operating temperature: 0 - +70 deg C.Multi-rate compliance for ethernet and fiber channel.Sub watt power consumption: 0.65W (typ.).Multipurpose multi-rate optical transceiver module for transmission at 1310nm over multimode fiber.Its sub watt power consumption and its excellent EMI performance allow system design with high port density.Warranty: 3 years limited.AddOn® SFP+ Module is built to meet or exceed the OEM's specifications and features 10GBase-LRM interface.

Addon SFP transceiver can be deployed with other OEM or 3rd party transceivers to provide seamless network performance. SFP transceiver is 100 percent compliant with all networking product lines..Hard drive accessory type: SFP transceiver.Interfaces/ports: 1 x 100base-FX.Connectivity media: 62.5/125 um multi-mode optical fiber, 50/125 um multi-mode optical fiber.Form factor: SFP.Range: 2 km.Data rate: 100 Mbps fast Ethernet half/full-duplex.Compatibility: Cisco catalyst 3750, 3560, and 2970 series switches.Fiber type: Multi-mode fiber.Application: Data networking.Connectivity: Wired.Transceivers initialize and perform identically to the OEM transceivers and can be mixed and deployed with other OEM or 3rd party transceivers, for seamless network performance.Certifications & Standards: MSA.Warranty: Lifetime limited.Addon® SFP transceiver is a hot-swappable input/output device that plugs into a gigabit ethernet slot and operates at 1310 nm over multi-mode fiber.
