SFP to RJ45 Converters

The Transition Networks® SGFEB1040-130-NA 1-port RJ-45 to SFP standalone fast Ethernet media/rate converter features auto negotiation, autocross, link pass through, far end fault and remote fault detect for efficient troubleshooting. It supports multimode or single mode fiber and IEEE802.3az Ethernet. This converter offers data rate of 10/100/1000 Mbps for copper and 1000 Mbps for fiber..Stand-alone media/rate converter is a cost effective method for integrating 1000Base-SX/LX fiber into a 10/100/1000Base-T copper environment.Dimensions: 1"H x 3.25"W x 4.8"D.Suitable for use with PC.Comes in black color.Interfaces/ports: One 10/100/1000Base-T RJ-45, one 100/1000Base-X SFP slot.Power supply: 7.5 - 24 VDC, provided by wide input AC wall mount adapter, Consumption: 2.2 W.LEDs: PWR (power), LACT (fiber link/activity), RJ-45 upper left (green/amber), RJ-45 upper right (speed).Data rates: 10/100/1000 Mbps (copper), 1000Mbps, 100Mbps also supported via SFP port (fiber).Form factor: Rack-mountable, wall mountable, rail-mountable, desktop.IEEE standards: IEEE 802.3, 802.3ab, 802.3u, 802.3z, 802.3az, Switches: Auto-negotiation enable/disable, link pass through enable/disable.Frame size: 10260 byte jumbo frames, RAM buffer: 512KB, MAC addresses: 8K.Features auto-MDI/MDIX, auto-negotiation, link pass through, far-end-fault (FEF) detection and remote fault detect.Temperature: 0 - 50 deg C operating, -15 - 65 deg C storage, Humidity: 5 - 95 percent non-condensing.Meets EN55022 Class A, EN55024, FCC Class A, CE Mark, UL, UL60950, CSA certifications and standards.Weight: 2 lbs..Comes with lifetime warranty

The Transition Networks® M/GE-PSW-SFP-01-NA mini GbE media converter provides cost-effective and entry level media conversion of 10/100/1000Base-T stand alone copper connection to 1000Base-X fiber connections. This hot swappable media converter has dual speed SFP port that supports autosensing 100 m or 1000 m SFP transceivers. The LEDs of the converter provide quick status information. This converter features auto-negotiation, auto-MDI/MDIX, automatic link restoration and fixed full duplex on fiber..Media converter provides cost-effective and entry level media conversion.Dimensions: 0.85"H x 1.8"W x 3.3"D.Comes in black color.Interfaces/ports: 1 x 10/100/1000Base-T RJ-45 to 100/1000Base-X SFP slot.Ethernet technology: Gigabit Ethernet.Power supply: Input: 4.5 VDC - 14 VDC, external AC/DC required, 12 VDC, 0.5 A, consumption: 2.4 W.Status LEDs: PWR (power) below RJ-45: On = Power, FX-link/act upper Left on RJ-45: On = link, TX-link/act upper right on RJ-45: On = link.Auto-negotiation, fixed full-duplex on fiber, auto-MDI/MDIX.Automatic link restoration, jumbo frame up to 10240 bytes.Temperature: 0 - 50 deg C operating, -15 - 65 deg C storage, humidity: 5 - 95% (non-condensing).Meets safety: Wall mount power supply, UL, cUL (Canada), FCC class A, CISPR22/EN55022 class A, EN55024, CE Mark standards.Weight: 2 lbs..Comes with lifetime warranty.Mini gigabit Ethernet media converter provides a cost-effective method for integrating fiber optic cabling into a 10/100/1000 UTP environment.

This media converter by Tripp Lite converts a single-mode or multimode fiber optical signal to a copper Ethernet signal that extends both power (48 VDC) and 10/100/1000 Mbps Gigabit Ethernet to a PoE+ (Power over Ethernet) device. Because Cat5e/6 cables are limited to only 100 meters, it is more effective to couple the N785-P01-SFP with fiber cable to reach greater distances. This could include providing both data and power to PoE and PoE+ devices, such as security cameras, VoIP telephones, point-of-sale kiosks, and access control devices..Customizable media converter extends power and data to a PoE+ device via fiber cable.Dimensions: 0.98"H x 3.74"W x 2.76"D.Network compatibility: 10/100/1000 Mbps Gigabit Ethernet network.Features a compact black metal housing.PoE saves you the expense and effort of purchasing, connecting and installing individual power supplies for each device.Supports auto-sensing of network speed and other advanced functions, such as automatic network speed sensing, full/half-duplex auto-detection and automatic MDI/MDI-X configuration.Supports both full- and half-duplex operation.Customizable SFP port supports both 1G single- and multimode transceivers.RJ45 jack supports auto MDI/MDI-X to bridge various network devices.Six LEDs indicate the converter's power, PoE, Ethernet network, and fiber link statuses at a glance.Completely plug-and-play with no additional software required for connection.The included power supply connects to a convenient AC outlet with no computer or other signal source needed.Works in tandem with Tripp Lite N785-Series non-PoE converters (sold separately).Pack includes: media converter, external power supply with 3.6' cord and NEMA 5-15P plug (input: 100-240V, 50/60 Hz, 1.5A; output: 48V 1.25A), and owner's manual.Meets or exceeds FCC and RoHS standards.2-year manufacturer limited warranty

PoE+ Industrial Fiber to Ethernet Media Converter 60W - SFP to RJ45 - Singlemode/Multimode Fiber to Copper Gigabit Ethernet - Compact Size - IP-30/ -40 to +75C (IMC1GSFP60W).EXTEND, CONVERT, POWER: Fiber to Ethernet media converter with PoE extends & converts fiber to RJ-45 copper; Provides up to 60W of PSE power to PoE/PoE+/PoE++ PD devices like cameras and sensors.FLEXIBLE POWER: Can be hardwired using terminal block (48-56VDC) power or powered using a standard Type-N barrel wall adapter (not included).OPEN SFP SLOT: Any MSA compliant SFP can be used for the incoming multimode or singlemode fiber connection; easy deployment across applications or fiber cable types.ROBUST DESIGN: Industrial Gigabit Media Converter w/MTBF 500,000+hrs @ 50C | Vibration, shock & free fall rated | Rugged IP-30 aluminum housing | Hardened operating temp -40C to 75C.STARTECH.COM ADVANTAGE: IT professionals' choice for over 30 years | This media converter is backed for 2-years by StarTech.com, including free 24/5 North America based multi-lingual tech support.Industrial PoE Media Converter | 10/100/1000 Mbps | 60 Watts | Open SFP | DIN Rail Mountable

The StarTech MCM1110 Gigabit Ethernet fiber media converter has a compact standalone design and wall mounting option to provide easy and worry-free installation. This converter features a durable metal housing that delivers superior performance. Plug-and-play installation helps for a hassle-free setup. Its compact, lightweight design fits nicely into any carrying case that lets you carry wherever you go. This media converter converts a copper RJ45 Ethernet connection to Gigabit fiber to extend your network over longer distances..Gigabit ethernet fiber media converter converts a copper RJ45 Ethernet connection to Gigabit fiber to extend your network over longer distances.Dimensions: 1"H x 2.8"W x 3.7"L.Compatible with networks 10/100/1000 Mbps.Brown steel enclosure for durability.Maximum data transfer rate: 1 Gbps, MTBF: > 50000 hours at 25 deg C, Fiber type: Multi mode, single mode, Fiber operating mode: Full-duplex.Has one RJ-45 female and one SFP slot female connector.LED indicators: 1 x power, 1 x fiber port link/act, 1 x copper port link/act, 1 x 1000 Mbps.Power: 1 A input current, 100 - 240 VAC input voltage, 2 A output current, 5 VDC output voltage, Plug type: N, Power consumption: 5 W max.Form factor: Desktop/wall mountable.Temperature: 32 - 122 deg F operating, 14 - 158 deg F storage, Humidity: 5 - 95% RH (non-condensing).10/100/1000 Mbps compatible RJ45 port supports auto negotiation to bridge different network speeds and devices to a Gigabit fiber network.Compact standalone design and wall mounting option offers easy and convenient installation.Converter offers a powerful networking solution for campuses, businesses, government facilities, stadiums, or other areas requiring network access.Supports Auto MDIX and 9K jumbo frame.Gigabit Open SFP slot to customize the network extension distance to your requirements with virtually any MSA-compliant multi/single mode transceiver.Contains universal power adapter (NA/EU/UK/AU).Meets IEEE 802.3 10BASE-T, IEEE 802.3u 100BASE-TX, IEEE 802.3ab 1000BASE-T, IEEE 802.3z 1000BASE-SX certification and standards.Weight: 6.5 oz..Comes with 2 years limited warranty.The StarTech Gigabit Ethernet fiber media converter with open SFP slot offers connectivity to users in an isolated area of a large complex or in a separate building.

Industrial Fiber to Ethernet Media Converter - 1Gbps SFP to RJ45/ Cat6 - Singlemode/Multimode Optical Fiber to Copper Gigabit Network - 12-56V DC - IP-30/ -40 to +75C (IMC1GSFP).INDUSTRIAL FIBER TO ETHERNET MEDIA CONVERTER: Extends & converts 1Gbps fiber to RJ45 copper w/ hardened operating temp -40C to 75C; powered by 12V-56V DC for compatibility with solar, auto & rail.OPEN SFP SLOT: Compatible with any standard SFP and can be used for multimode or single mode fiber connections; easy deployment across applications, fiber distances or fiber cable types.ROBUST DESIGN: Industrial Gigabit Network Media Converter w/MTBF of 500,000+ hrs @ 50C | Vibration, shock & free fall rated | Rugged IP-30 aluminum housing.STARTECH.COM ADVANTAGE: IT professionals' choice for over 30 years; this media converter is backed for 2-years by StarTech.com, including free 24/5 North America based multi-lingual tech support.TECH SPECS: 1 Gbps | 12V-56VDC | Single Mode SMF & Multi-Mode MMF Fiber | 16K Jumbo Frames | LFP | IP-30 Housing | DIN or Wall Mountable | Terminal Block and/or Barrel Adapter for power redundancy.Gigabit Media Converter | SFP to RJ45 (Cat6) | MTBF: 500,000+hrs @ 50°C | 12V-56VDC

The StarTech.com® GLCTST hot-pluggable SFP transceiver ensures a reliable GbE connection up to 100 m using RJ-45 connector. This transceiver offers port flexibility to match your changing needs over time, from copper to fiber..Hot-pluggable transceiver provides reliable and cost effective GbE connection using RJ-45 connector.Dimensions: 0.6"H x 0.5"W x 2.7"D.Comes in silver color with aluminum enclosure.Interfaces/port: 1 x RJ-45 female.Ethernet technology: Gigabit Ethernet.Media type supported: Twisted pair.Maximum data transfer rate: 1 Gbps.Operating range: 100 m.Compatible with Mini-GBIC fiber (MM or SM) and copper (RJ45) slots (NICS, fiber media converters).Ideal for use in switches, routers and other networking equipment, SFP allows to expand your network to remote segments cost-effectively.It provides a versatile and convenient solution that is compatible with a multitude of multi and single-port Gigabit Ethernet networking devices.Meets RoHS, WEEE standards.Weight: 0.9 oz..Comes with lifetime warranty

The Omnitron miConverter™ 1239-0-1 miniature transceiver/fiber media converter supports 1000Base-X, 1000Base-BX-D, 1000Base-T, 1000Base-ZX, 1000Base-BX10-U, 1000Base-BX and 1000Base-LX/SX networks. This SFP-type converter enables easy adaptability to different fiber types and supports CWDM technology to increase the bandwidth of fiber infrastructure with speed and distance. It facilitates a plug-and-play option with multi-mode and single-mode optical fiber..Transceiver/media converter supports 10BASE-T, 100BASE-TX, 1000BASE-T, 1000BASE-X and the IEEE 802.3 network specifications.Dimensions: 0.84"H x 1.71"W x 4.1"D.Interfaces/port: 1 x Network (RJ-45), 1 x SFP.Ethernet technology: Ethernet, Fast Ethernet, Gigabit Ethernet.Media type supported: Twisted pair, optical fiber, Network technology: 1000Base-X, 1000Base-BX-D, 1000Base-T, 1000Base-ZX, 1000Base-BX10-U.Form factor: Rack-mountable, desktop, external, wall mountable.Power: 100-240 VAC/60 Hz, 5-12 VDC via 2.5 mm barrel input voltage.Jumbo frame support: Up to 10240 bytes, MTBF: 250000 hours.Supports MDI/MDIX auto-crossover, cost-effective mounting and proven solution.Includes US power supply - 120-240 V/50-60 Hz, velcro strip, user manual.Meets RoHS, WEEE, UL, CE, FCC Class A standards.Comes with lifetime warranty

The Transition Networks M/GE-ISW series is a hardened Gigabit Ethernet mini media converter that provides cost-effective media conversion between 10/100/1000Base-T RJ-45 port and 100/1000Base-X open SFP slot for hardened or outdoor environments. With its supported operating temperature range of -40 degree Celcius to +75 degree Celcius, the mini converter offers a space-saving alternative for converting copper to fiber in extreme environments..Mini Gigabit Ethernet media converter provides simple and cost-effective integration of copper and fiber equipment.Dimensions: 0.85"H x 1.8"W x 3.3"D.Comes in black.Interfaces: 1 x RJ-45 10/100/1000Base-T, 1 x SFP 100/1000Base-X.Features auto MDI/MDIX, copper and fiber auto-negotiation.Supports fixed full-duplex operation on the fiber port.Offers jumbo frame (up to 10240 bytes) support and active link pass-through for reliable data transfer.Unit and port LEDs allow for quick status information.Supports DC and AC input power via terminal block.Provides overload current and reverse polarity protection.Can be mounted with an included DIN rail clip and Velcro or wall mount bracket (sold separately).Meets or exceeds FCC Class A standard.Lifetime manufacturer limited warranty
