Single-Mode SFP Transceivers

The Cisco transceiver module has one LC duplex 10GBase-LR port, and it is compatible with the Alcatel-Lucent Omniswitch 6900, making it easy to install and use with your system. The piece is hot swappable and allows you to select the interface of your choice for flexibility. It is the smallest 10G form factor, so it saves you space..Interfaces/ports: 1 x LC duplex 10GBase-LR.Dimensions: 0.3"(H) x 1/2"(W) x 2.2"(D).Compatibility: Alcatel-lucent omniswitch 6900.Smallest 10G form factor.Supports 10GBASE Ethernet and OTU2/OTU2e.Hot-swappable input/output device that plugs into an Ethernet SFP+ port of a Cisco switch.Provides flexibility of interface choice.Optical interoperability with 10GBASE XENPAK, 10GBASE X2, and 10GBASE XFP interfaces on the same link.Supports "pay-as-you-populate" model.Supports digital optical monitoring capability.Supports the cisco quality identification (ID) feature that enables a Cisco switch to identify whether the module is certified and tested by Cisco.Form factor: Hot-swappable.Cisco Transceiver Module - Switch Accessories for Networking

The Cisco™ GLC-TE= Gigabit Ethernet SFP transceiver module is suitable for 7700 F3-series, 9372PX and 9396PX Cisco Nexus series switches. This SFP transceiver module has RJ-45 1000Base-T network LAN ports for connectivity. It supports twisted pair media for reliable data transfer..SFP transceiver module for 7700 F3-series, 9372PX and 9396PX Cisco Nexus series switches.Color: Silver.Connectors: One RJ-45 1000Base-T network LAN.Media type supported: Twisted pair.Ethernet technology: Gigabit Ethernet

To ensure that specifications are met over FDDI-grade, OM1 and OM2 fibers, the transmitter should be coupled through a mode conditioning patch cord. No mode conditioning patch cord is required for applications over OM3..SFP+ module is perfect for data networking, optical network.Dimensions: 0.3"H x 0.5"W x 2.2"D.Compatible with A9K-16T/8-B=, ME-3600X-24FS-M=, ME-3600X-24TS-M, N7K-F132XP-15=, N7K-M132XP-12L, WS-X45-SUP7-E/2 networking products.Interface/ports: 1 x LC duplex 10GBase-LRM network.Media type supported: Optical fiber, fiber mode supported: Multi-mode, single-mode, Ethernet technology: 10 Gigabit Ethernet.Maximum data transfer rate: 10 Gbps.Form factor: Hot-swappable, plug-in module.Up to 980', fiber optic cable standard: 62.5 ohm m, 50 ohm m, wavelength: 1300nm.Supports link lengths of 220m on standard fiber distributed data interface (FDDI) grade multimode fiber (MMF).Temperature range: 32 - 158 deg F.Transmit power: -6.5 to 0.5 dBm.Receive power: -8.4(in average) and -6.4 (in OMA) - 0.5 dBm.Connectivity media: 62.5 um, 50 um multi-mode fiber 10GBase-LRM, single-mode fiber 10GBase-LRM.Power consumption: 1 W.Core size: 62.5 - G.652 microns.Cable distance: 220 - 300 m.Cable type: MMF and SMF.Transmit and receive wave length: 1260 - 1355nm.Compliant standards: IEEE 802.3ae, IEC 60825-1, laser class 1.Warranty: 90 days limited.10GBase-LRM SFP transceiver module supports link lengths of 220 m on standard fiber distributed data interface (FDDI) grade multimode fiber (MMF).

The Transition Networks® TN-GLC-SX-MM 1000Base-SX Gigabit Ethernet SFP transceiver module is suitable for Gigabit Ethernet switches and routers, fiber channel switch infrastructure, xDSL applications and metro edge switching. This hot pluggable transceiver module with LLC 1000Base-SX interface, transfers data at the rate of 1.25 Gbps up to 550 m distance over multi-mode fiber media at a wavelength of 850 nm. This transceiver module helps to install in any SFP port allowing for 1000Base-SX interface to the network through the SFP connector..Hot-pluggable SFP transceiver module is suitable for Gigabit Ethernet switches, routers, fiber channel switch infrastructure and xDSL applications.Dimensions: 0.33"H x 0.52"W x 2.18"D.Supports multi-mode fiber (MMF) connection media.Interfaces/ports: One LC 1000Base-SX.Ethernet technology: Gigabit Ethernet.Maximum data transfer rate: 1.25 Gbps.Reach: 550 m.Wavelength: 850 nm.Media type supported: Optical fiber.Link budget: 8.5 dB.Power: 3.3 V, Power consumption: 0.66 W.Temperature range: 0 - 70 deg C operating, 40 - 85 deg C storage.Fiber optic cable standard: 62.5/125 u m, 50/125 u m.SFP footprint LC optical transceiver.Has been designed to install in any SFP port while allowing for 1000Base-SX interface to the network through the SFP connector.Meets MSA, IEC-60825, FDA 21, CFR 1040.10 and 1040.11, IEEE 802.3 2003, ANSI X3.297-1977 certifications and standards.Comes with lifetime warranty

Cisco™ Downstream SFP module is a hot-swappable I/O device that plugs into a gigabit Ethernet slot and linking it with the fiber-optic network. Module supports data networking applications and offers data transfer rate of 1 Gb/s..1 x LC 1000Base-BX.0.3"(H) x 0.5"(W) x 2.2"(D).Cisco ME 2400, Catalyst 2960 series, Cisco ME 3400, Catalyst 3560 series, Catalyst 3750 series, Catalyst 4500 series, Catalyst 4900 series, Catalyst 6500 series.Wired.Connectivity media: G.652 microm single-mode optical fiber.Form factor: Hot-swappable.Management: Digital optical monitoring (DOM) functions, Application/usage: Data networking.Data transfer rate: 1 Gbps gigabit ethernet.Operating transmission range: Up to 10 km.Small form-factor pluggable (SFP) gigabit interface converter is a hot-swappable input/output device that plugs into a Gigabit Ethernet-port or slot, linking the-port with the network.1490-nm TX/1310-nm RX wavelength.Warranty: 90 days limited.Cisco™ Downstream SFP module has the ability to go up to 10 km over G.652 microm single-mode optical fiber and features digital optical monitoring functions.

Industry standard Cisco small form factor pluggable (SFP) gigabit interface converter is a hot-swappable input/output device that plugs into a gigabit Ethernet port or slot, linking the port with the network..Interfaces/ports: 1 x LC duplex 1000Base-LX/LH.Dimensions: 0.3"(H) x 1/2"(W) x 2.2"(D).Compatibility: Cisco IE 3000 series switches, cisco 3200 series rugged routers, cisco MWR 2900 mobile wireless routers.Connectivity technology: Wired.Connectivity media: Single mode fiber 1000Base-LX/LH.Operating temperature: -40 - 185 deg F.Fiber type: SMF/MMF.Cabling type: Ethernet 1000Base-LX.Additional information: Spare product, range: 10 Km, wavelength: 1300 nm.Data transfer rate: 1 Gb/s gigabit Ethernet.Form factor: Hot swappable/plug-in.Application/usage: Data networking.SFP (mini-GBIC) transceiver module 1000 MBPS SFP single mode rugged 1000BASE-LX/LH SFP for MMF and SMF.

The Cisco SFP-10G-LR-S= SFP+ module measuring 0.3" x 0.5" x 2.2", supports a link length of 10 km on standard single-mode fiber. It has LC/PC duplex 10GBase-LR network interface for optimal connectivity. This hot-swappable module transmits data over optical fiber media..SFP+ module is suitable for SMF.Dimensions: 0.3"H x 0.5"W x 2.2"D.Has one LC/PC duplex 10GBase-LR network port for connectivity.Supports 10 Gigabit Ethernet technology for high speed connectivity.Supports single-mode fiber.Optical fiber media for quick data transfer.Network technology: 10GBase-LR.Form factor: Hot-swappable.Perfect for both data and optical networking.Weight: 2.65 oz..Comes with 1 year limited warranty

Omnitron Pluggable optical transceiver operates at 850 nm wavelength and covers a maximum distance of up to 1800'. Transceiver is compatible with iConverter media converter modules, T1/E1 MUXes and network interface devices..Interfaces/ports: 1 x LC 1000Base-SX.Connectivity media: Multi-mode optical fiber.Ethernet technology: Gigabit Ethernet.Form factor: Plug-in module.Data rate: 1 Gbps.Cable distance: 550 meters.Wavelength: 850 nm.Application/usage: Data networking.Connectivity technology: Wired, Min. Tx Power (dBm): -9.5, Max. Tx Power (dBm): -4,Min. Rx Sense (dBm): -17, Max. Rx Power (dBm): -3, Link budget (dBm): 7.5.Low EMI metal enclosure, supports a wide variety of cable types.Digital diagnostic capability.Pluggable optical transceivers enable flexible fiber and copper connectivity.Warranty: Lifetime.Omnitron Pluggable optical transceiver transfers data at a rate of 1 Gb/s and enables a single network device to connect to a wide variety of fiber optic cable types.

Cisco™ 100Base-LX10 rugged SFP module has wavelength of 1310 nm and is compatible with Cisco™ IE 3000 series switches. Module is used in data networking and has single-mode optical fiber 100Base-LX10 media connectivity..Dimensions: 0.3"(H) x 0.5"(W) x 2.2"(D).For Cisco IE 3000 series switches.Hot-swappable when deployed, the switch or router does not have to reboot.Interfaces/ports: 1 x LC duplex 100Base-LX10.Application/usage: Data networking.Data transfer rate: 100 Mbps fast ethernet.Connectivity technology: Wired.Form factor: Hot-swappable.Connectivity media: Single-mode optical fiber 100Base-LX10.Wavelength: 1310 nm.Max transfer distance: 6.2 miles.Operating temperature: -40 - 185 deg F.Supports the Cisco quality ID feature that enables the switch or router to identify whether or not the SFP is a Cisco qualified SFP.Compliant and standards: IEEE 802.3, IEEE 802.3ah.Warranty: 90 days limited.Cisco™ 100Base-LX10 rugged SFP module operates on ordinary single-mode fiber-optic link that spans up to 10 km long and has hot-swappable form factor.

Cisco™ 1000BASE-BX10 Upstream SFP module is a hot-swappable input/output device that plugs into a gigabit ethernet port or slot. SFP is compatible with Cisco™ ME 2400, catalyst 2960 series, Cisco™ ME 3400 and catalyst 3560 series..10/100/1000Base-T Gigabit Ethernet.Form factor: Hot-swappable, spare product, 1310-nm TX/1490-nm RX wavelength, operating transmission range up to 10 km.Interfaces: 1 x LC 1000Base-BX.Connectivity media: G.652 micrometer single-mode optical fiber.Management: Digital optical monitoring (DOM) functions.Application/usage: Data networking.Compatibility: Cisco ME 2400, Catalyst 2960 series, Cisco ME 3400, Catalyst 3560 series, Catalyst 3750 series, Catalyst 4500 series, Catalyst 4900 series, Catalyst 6500 series.Dimensions: 0.3"(H) x 0.5"(W) x 2.2"(D).Warranty: 90 days limited.Cisco™ 1000BASE-BX10 Upstream SFP module can be used for data networking and has 1 Gb/s data transfer rate.

The Cisco small form-factor pluggable portfolio offers customers a wide variety of high-density and low-power 25 Gigabit Ethernet connectivity options for data center and high-performance computing networks applications. The 25G Modules are based on SFP28 form factor..Transceiver module for MMF.Pull tab comes in beige.Supports a link length of 70/100m on OM3/4 MMF.Requires RS-FEC on the host ports.Maximum power consumption: 1.2W.Wavelength: 850nm.Cable type: MMF.Core size: 50 microns.Modal bandwidth: 2000 OM3/4700 OM4/4700 OM5 on 70/100/100m cable distances.Support FCoE with the appropriate host s/w support.5-year manufacturer limited warranty

The Omnitron 01-01-7207 SFP optical transceiver enables a single network device to connect to a wide variety of flexible fiber and copper cable through its interchangeable, compact media connectors. It is compatible with iConverter®, FlexPoint™, OmniConverter™ and miConverter™ products to meet specific network protocols and media requirements. This transceiver supports digital diagnostic by providing enhanced diagnostic information. The compact design and the ease of interchangeability of this unit provide a flexible solution for network designs..Optical transceiver module is compatible with iConverter media converter modules, T1/E1 multiplexers and network interface devices.LC duplex 1000Base-LX network.Media type supported: Optical fiber, fiber mode supported: Single-mode, fiber optic cable standard: 9/125 ohm m.Form factor: Hot-pluggable, hot-swappable, data transfer rate: 1.25 Gbps.Compatible with FlexPoint, OmniConverter and miConverter media converter modules that support SFP transceivers.Compliant with IEEE 802.3u fast Ethernet and 802.3z gigabit Ethernet specifications.Supports operational data rates for SONET OC-3/12/48, SDH STM-1/4/16 and fiber channel x1/x2.Supports a wide variety of cable types, supports digital diagnostic capability, low EMI metal enclosure.Temperature: 0 to 50 deg C commercial, -40 to 80 deg C storage.Meets RoHS, Green, WEEE standards.Comes with 1 year warranty.Certifications and standards: Compliant with MSA SFF-8472 standard.OMNITRON SYSTEMS iConverter 1000Base-LX SFP Optical transceiver supports data transfer rate of 1 Gb/s and is suitable to use with networking applications.

The Cisco 10/25GBASE-LR Module supports a link length of 10 kilometers on standard Single-Mode Fiber (SMF) G.652 at both 10G and 25G. This module requires RS-FEC on the host ports for operation at 25G..This 10/25GBASE-LR module supports a link length of 10km on standard Single-Mode Fiber (SMF) G.652 at both 10G and 25G.Max power consumption: 1.3W.Meets or exceeds the IEEE 802.3by and IEEE 802.3cc standards.Certified and tested on Cisco SFP28 ports for superior performance, quality, and reliability.This module requires RS-FEC on the host ports for operation at 25G.Transmit and receive wavelength: 1260-1355nm (10G) and 1295-1325nm (25G)

Startech.com® SFP+ Hot pluggable transceiver module sustain data rates up to 11.1 Gbps and DDM while it can be installed on any fiber networking cable. Module does not require any rebooting and support a distance of 300m..Interfaces/Ports: 1 x 10GBase-SR.Dimensions: 0.4inch(H) x 0.5inch(W) x 2.4inch(D).Compatibility: MSA compliant.Interfaces/ports details: 1 x LC female 10GBase-SR network.Wavelength: 850 nm.Fiber operating mode: half/full-duplex.Fiber type: Multi-mode.Maximum data rates up to 11.1 Gbps.Operating temperature: 0 to 70 deg c, storage temperature: - 40 to 85 deg c, operating humidity: 30 to 70% RH.Local unit connectors: 1 - fiber optic LC female.Warranty: 3 years limited.Startech.com® SFP+ Transceiver module is a compact set used for both telecommunication as well as data communication applications while it upgrades a 10Gb SFP+ multimode LC port on fiber media converter.

The Cisco® 40GBase-SR4 QSFP+ wired transceiver module offers links up to 492' long via multi-mode optical fiber at a wavelength of 840 - 860 nm. It supports both twisted-pair and optical fiber media types. This Hot-swappable, plug-in module allows high-bandwidth 40G optical links over 12-fiber parallel fiber terminated with MPO/MTP multifiber connectors..QSFP+ transceiver module for data networking and optical network.Dimensions: 0.5" x 0.7" x 2.9".Interfaces/ports: One MPO/MTP 40GBase-SR4 network.Max transfer distance: 492', Optical wave length: 840 - 860 nm.Media type supported: Optical fiber, Fiber mode supported: Multi-mode.Connectivity technology: Wired.Form factor: Hot-swappable, plug-in module.Power consumption: 1.5 W operational.Temperature: 32 - 158 deg F (operating), -40 - 185 deg F (storage).Meets FCC CFR21 Part 1040, GR-1435-CORE, GR-20-CORE, GR-326-CORE, IEC 60825-1 Class 1, MSA SFF-8431 certifications and standards.Comes with 1 year limited warranty

Cisco® Transceiver module features wired connective technology and has 1 x network - ethernet 1000Base-Sx - LC/PC multi-mode x 2 ports for cabling. Transceiver module is compatible with PC..Interfaces/ports: 1 x network - ethernet 1000Base-SX - LC/PC multi-mode x 2.Dimensions: 0.3"(H) x 1/2"(W) x 2.2"(L).Compatability: PC.Connectivity technology: Wired.Wavelength: 850 nm.Operating distance: 0.6 miles.Form factor: Plug in module, hot swappable.Fibre type: Multimode.Cabling type: 1000Base-SX.Cisco® GLC-SX-MMD= Transceiver Module has 1 x network - ethernet 1000Base-SX - LC/PC multi-mode x 2 ports.
