Single-Mode Fiber to Ethernet Converter

Tripp Lite media converter lets you extend your copper Gigabit Ethernet network connection up to 12.4 miles over fiber optic cable. Because Cat5e/6 cables are limited to only 100 meters, it is more effective to couple the N785-INT-SC-SM with single mode fiber cable to reach greater distances. This could include providing network connectivity to employees in a secluded area of a facility, college or branch office or connecting multiple office workstations to a switch located in a separate building..Gigabit single-mode fiber to Ethernet media converter.Dimensions: 1"H x 3.7"W x 2.76"D.Comes in black.Extends your copper Gigabit Ethernet network past the standard 328' limit.Supports single-mode fiber optic cable with SC connectors.RJ45 jack supports auto-MDI/MDIZ to bridge various network devices.Supports both full- and half-duplex operation.Compact metal converter is easy to install and set up with no software or drivers required.Package includes: media converter, four international plug adapters (North America, UK, Europe, Australia), international power supply (input: 100-240V), and owner's manual.2-year manufacturer limited warranty

Startech.com® Single mode fiber media converter transforms and extends a 10/100 Mbps Ethernet connection up to 18.6 miles/30 km. Converter features rugged steel casing for durability in harsh environments..Interface/ports: 1 x RJ-45 female, 1 x fiber-optic SC female.Dimensions: 0.9"(H) x 3.4"(W) x 6.1"(L).Compatibility: PC.Connectivity technology: Wired.Form factor: Desktop, rack mountable.Black.Fiber optic mode: Single mode, half/full-duplex operating mode.Max transfer distance: 30 km (18.6 mi).Data transfer rate: 200 Mbps (full-duplex mode).Environment conditions: Operating temperature: 0 - 60 deg C, Storage temperature: -10 - 70 deg C, Humidity: 10 - 90% RH.Input voltage: 115 - 230 AC.Output voltage: 12 DC, output current: 1A.Center tip polarity: Positive.Includes 1 x fiber media converter, 1 x universal power adapter (NA/UK/EU), 1 x instruction manual.Certifications and standards: RoHS, IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, FC, FCC.Weight: 14 oz..Warranty: 2 years limited.Startech.com® Single mode fiber media converter lets to extend a fast Ethernet network over single mode fiber and supports standalone operation or installation into the 20 slot.

Startech.com® Single mode fiber media converter transforms and extends a gigabit Ethernet connection up to 24.8 miles/40 km over single mode LC fiber. Converter features rugged steel casing for durability in harsh environments..Interface/ports: 1 x RJ-45 female, 1 x fiber-optic LC female.Dimensions: 0.9"(H) x 3.4"(W) x 6.1"(L).Compatibility: PC.Connectivity technology: Wired.Form factor: Desktop, rack mountable.Black.Fiber optic mode: Single mode, half/full-duplex operating mode.Data transfer rate: 2000 Mbps (full-duplex mode).MTBF: 65,000 hours.Perfect for secure connections required by government agencies where EMI is not acceptable.Provides connectivity to a user or network segment that is in an isolated area of a large complex or in another building altogether.Environment conditions: Operating temperature: 0 - 60 deg C, Storage temperature: -10 - 70 deg C, Humidity: 10 - 90% RH.Input voltage: 115 - 230 AC.Output voltage: 12 DC, output current: 1A.Center tip polarity: Positive.Includes 1 x fiber media converter, 1 x universal power adapter (NA/UK/EU), 1 x instruction manual.Certifications and standards: RoHS, IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, FC, FCC.Weight: 14.7 oz..Max transfer distance: 85 ft 62.5 microm optical fiber 160 MHz, 108.90 ft 62.5 microm optical fiber 200 MHz, 216 ft 50.0 microm optical fiber 400 MHz, 270 ft 50.0 microm optical fiber 500 MHz, 984 ft 50.0 microm optical fiber 2 GHz, 1312 ft 50.0 microm optical fiber.Warranty: 2 years limited.Startech.com® Single mode fiber media converter enables to extend a gigabit Ethernet network over single-mode fiber and supports full gigabit speeds for ideal network performance.

This media converter by Tripp Lite converts a single-mode or multimode fiber optical signal to a copper Ethernet signal that extends both power (48 VDC) and 10/100/1000 Mbps Gigabit Ethernet to a PoE+ (Power over Ethernet) device. Because Cat5e/6 cables are limited to only 100 meters, it is more effective to couple the N785-P01-SFP with fiber cable to reach greater distances. This could include providing both data and power to PoE and PoE+ devices, such as security cameras, VoIP telephones, point-of-sale kiosks, and access control devices..Customizable media converter extends power and data to a PoE+ device via fiber cable.Dimensions: 0.98"H x 3.74"W x 2.76"D.Network compatibility: 10/100/1000 Mbps Gigabit Ethernet network.Features a compact black metal housing.PoE saves you the expense and effort of purchasing, connecting and installing individual power supplies for each device.Supports auto-sensing of network speed and other advanced functions, such as automatic network speed sensing, full/half-duplex auto-detection and automatic MDI/MDI-X configuration.Supports both full- and half-duplex operation.Customizable SFP port supports both 1G single- and multimode transceivers.RJ45 jack supports auto MDI/MDI-X to bridge various network devices.Six LEDs indicate the converter's power, PoE, Ethernet network, and fiber link statuses at a glance.Completely plug-and-play with no additional software required for connection.The included power supply connects to a convenient AC outlet with no computer or other signal source needed.Works in tandem with Tripp Lite N785-Series non-PoE converters (sold separately).Pack includes: media converter, external power supply with 3.6' cord and NEMA 5-15P plug (input: 100-240V, 50/60 Hz, 1.5A; output: 48V 1.25A), and owner's manual.Meets or exceeds FCC and RoHS standards.2-year manufacturer limited warranty

Industrial Fiber to Ethernet Media Converter - 1Gbps SFP to RJ45/ Cat6 - Singlemode/Multimode Optical Fiber to Copper Gigabit Network - 12-56V DC - IP-30/ -40 to +75C (IMC1GSFP).INDUSTRIAL FIBER TO ETHERNET MEDIA CONVERTER: Extends & converts 1Gbps fiber to RJ45 copper w/ hardened operating temp -40C to 75C; powered by 12V-56V DC for compatibility with solar, auto & rail.OPEN SFP SLOT: Compatible with any standard SFP and can be used for multimode or single mode fiber connections; easy deployment across applications, fiber distances or fiber cable types.ROBUST DESIGN: Industrial Gigabit Network Media Converter w/MTBF of 500,000+ hrs @ 50C | Vibration, shock & free fall rated | Rugged IP-30 aluminum housing.STARTECH.COM ADVANTAGE: IT professionals' choice for over 30 years; this media converter is backed for 2-years by StarTech.com, including free 24/5 North America based multi-lingual tech support.TECH SPECS: 1 Gbps | 12V-56VDC | Single Mode SMF & Multi-Mode MMF Fiber | 16K Jumbo Frames | LFP | IP-30 Housing | DIN or Wall Mountable | Terminal Block and/or Barrel Adapter for power redundancy.Gigabit Media Converter | SFP to RJ45 (Cat6) | MTBF: 500,000+hrs @ 50°C | 12V-56VDC

The Transition Networks® SGFEB1040-130-NA 1-port RJ-45 to SFP standalone fast Ethernet media/rate converter features auto negotiation, autocross, link pass through, far end fault and remote fault detect for efficient troubleshooting. It supports multimode or single mode fiber and IEEE802.3az Ethernet. This converter offers data rate of 10/100/1000 Mbps for copper and 1000 Mbps for fiber..Stand-alone media/rate converter is a cost effective method for integrating 1000Base-SX/LX fiber into a 10/100/1000Base-T copper environment.Dimensions: 1"H x 3.25"W x 4.8"D.Suitable for use with PC.Comes in black color.Interfaces/ports: One 10/100/1000Base-T RJ-45, one 100/1000Base-X SFP slot.Power supply: 7.5 - 24 VDC, provided by wide input AC wall mount adapter, Consumption: 2.2 W.LEDs: PWR (power), LACT (fiber link/activity), RJ-45 upper left (green/amber), RJ-45 upper right (speed).Data rates: 10/100/1000 Mbps (copper), 1000Mbps, 100Mbps also supported via SFP port (fiber).Form factor: Rack-mountable, wall mountable, rail-mountable, desktop.IEEE standards: IEEE 802.3, 802.3ab, 802.3u, 802.3z, 802.3az, Switches: Auto-negotiation enable/disable, link pass through enable/disable.Frame size: 10260 byte jumbo frames, RAM buffer: 512KB, MAC addresses: 8K.Features auto-MDI/MDIX, auto-negotiation, link pass through, far-end-fault (FEF) detection and remote fault detect.Temperature: 0 - 50 deg C operating, -15 - 65 deg C storage, Humidity: 5 - 95 percent non-condensing.Meets EN55022 Class A, EN55024, FCC Class A, CE Mark, UL, UL60950, CSA certifications and standards.Weight: 2 lbs..Comes with lifetime warranty

PoE+ Industrial Fiber to Ethernet Media Converter 60W - SFP to RJ45 - Singlemode/Multimode Fiber to Copper Gigabit Ethernet - Compact Size - IP-30/ -40 to +75C (IMC1GSFP60W).EXTEND, CONVERT, POWER: Fiber to Ethernet media converter with PoE extends & converts fiber to RJ-45 copper; Provides up to 60W of PSE power to PoE/PoE+/PoE++ PD devices like cameras and sensors.FLEXIBLE POWER: Can be hardwired using terminal block (48-56VDC) power or powered using a standard Type-N barrel wall adapter (not included).OPEN SFP SLOT: Any MSA compliant SFP can be used for the incoming multimode or singlemode fiber connection; easy deployment across applications or fiber cable types.ROBUST DESIGN: Industrial Gigabit Media Converter w/MTBF 500,000+hrs @ 50C | Vibration, shock & free fall rated | Rugged IP-30 aluminum housing | Hardened operating temp -40C to 75C.STARTECH.COM ADVANTAGE: IT professionals' choice for over 30 years | This media converter is backed for 2-years by StarTech.com, including free 24/5 North America based multi-lingual tech support.Industrial PoE Media Converter | 10/100/1000 Mbps | 60 Watts | Open SFP | DIN Rail Mountable

The Transition Networks® 2-port RJ-45 to SC mini Gigabit Ethernet media converter is perfect for integrating fiber optic cabling into a 10/100/1000 UTP environment. It features unit and port LEDs for status information. This converter supports auto-negotiation, fixed link pass through and automatic link restoration for efficient troubleshooting. The AutoCross™ feature in this converter automatically detects and configures the twisted pair port to the correct MDI or MDI-X configuration..Mini Gigabit Ethernet media converter is a cost-effective method for integrating fiber optic cabling into a 10/100/1000 UTP environment.Dimensions: 0.85"H x 1.8"W x 3.3"D.Suitable for use with PC.Comes in black color.Interfaces/ports: One 10/100/1000Base-T RJ-45, one single mode SC.Power supply: Unit accepts 5 - 28 VDC wall mount AC adapter - 12 VDC 400 mA, Consumption: 3.15 W.LEDs: PWR (power) - (below RJ-45) ON = lit for normal operation, FX-link/act (fiber link/activity) - (upper left on RJ-45), ON = link.IEEE standards: IEEE 802.3.Frame size: 1632 bytes untagged, 1628 bytes tagged.Maximum distance supported: 6.21 mile.Features auto-MDI/MDIX, auto-negotiation, automatic link restoration, fixed link pass through and space saving design.Temperature: 0 - 50 deg C operating, -15 - 65 deg C storage, Humidity: 5 - 95 percent non-condensing.Meets UL, CSA, CISPR22/EN55022 Class A + EN55024, EN60950 Class A, FCC Class A, CE Mark certifications and standards.Weight: 2 lbs..Comes with lifetime warranty

TP-LINK MC220L Gigabit Media Converter, 1000Mbps RJ45 to 1000Mbps SFP slot supporting MiniGBIC modules, chassis mountable.Interfaces/ports: 1 x RJ-45 ethernet 1000Base-T - female.Dimensions: 1.1"(H) x 3.7"(W) x 2.9"(D).Connectivity technology: Wired.Wavelength: 850 nm/1310 nm (depends on the used SFP module).LED indicators: PWR, LINK, RX.Power supply: External power adapter.Form factor: External.Maximum distance supported: 6.2 mile.Works at 1000 Mbps in Full-Duplex mode for both TX port and FX port.Supports auto MDI/MDIX for TX port.Provides switch configuration of Force /Auto transfer mode for FX port.Easy-to-view LED indicators provide status to monitor network activity easily.Designed to convert 1000Base-FX fiber to 1000Base-T copper media or vice versa.Designed for use with single-mode fiber cable utilizing the SC-Type connector.Standards and protocols: IEEE 802.3ab, IEEE 802.3z, IEEE 802.3x.Temperature: 0 - 40 deg C (operating), -40 - 70 deg C (storage), humidity: 10 - 90% non-condensing (operating), 5 - 90% non-condensing (storage).Safety and emission: FCC, CE.Warranty: 1 year limited.TP-LINK MC220L Gigabit Media Converter, 1000Mbps RJ45 to 1000Mbps SFP slot supporting MiniGBIC modules, chassis mountable

The StarTech.com® ET91000SM20 GbE copper-to-fiber transceiver/media converter helps to convert and extend your GbE connection up to 20 km using single mode LC fiber connector. This media converter supports full and half-duplex operation with a maximum data transfer rate of 2 Gbps (full-duplex), as well as it supports auto negotiation or forced mode. This media converter is compatible with 1000Base-T, 1000Mbps Gigabit copper and 1000Base-LX fiber protocols..Transceiver/media converter converts and extends your GbE connection up to 20 km using single mode LC fiber connector.Dimensions: 0.9"H x 3.5"W x 6.4"D.Comes in steel color with plastic construction.Interfaces/port: 1 x fiber optic LC duplex female, 1 x RJ-45 female.Ethernet technology: Gigabit Ethernet.Media type supported: Single-mode optical fiber.Wavelength: 1310 nm.Maximum data transfer rate: 2 Gbps.Operating range: 20 km.Form factor: Rack-mountable, standalone.Power: 100 - 240 VAC input voltage, 12 VDC output voltage, 19.2 W power consumption, 0.48 A/1.6 A input/output current.Jumbo frame support: 9.6K max, MTBF: 65000 hours.LED indicators: 1 x PWR, 1 x RPF, 1 x LFP, 1 x LNK, 1 x LINK x RJ45, 1 x FULL RJ45.High-performance media converter supports a range of network setup and diagnostic protocols (for example, ALS and Auto MDIX).Heavy-duty fiber media converter is designed for maximum reliability.Includes universal power adapter (NA/EU/UK/AU), instruction manual.Meets RoHS, WEEE standards.Weight: 14.5 oz..Comes with 2 year warranty

The Omnitron miConverter™ 1239-0-1 miniature transceiver/fiber media converter supports 1000Base-X, 1000Base-BX-D, 1000Base-T, 1000Base-ZX, 1000Base-BX10-U, 1000Base-BX and 1000Base-LX/SX networks. This SFP-type converter enables easy adaptability to different fiber types and supports CWDM technology to increase the bandwidth of fiber infrastructure with speed and distance. It facilitates a plug-and-play option with multi-mode and single-mode optical fiber..Transceiver/media converter supports 10BASE-T, 100BASE-TX, 1000BASE-T, 1000BASE-X and the IEEE 802.3 network specifications.Dimensions: 0.84"H x 1.71"W x 4.1"D.Interfaces/port: 1 x Network (RJ-45), 1 x SFP.Ethernet technology: Ethernet, Fast Ethernet, Gigabit Ethernet.Media type supported: Twisted pair, optical fiber, Network technology: 1000Base-X, 1000Base-BX-D, 1000Base-T, 1000Base-ZX, 1000Base-BX10-U.Form factor: Rack-mountable, desktop, external, wall mountable.Power: 100-240 VAC/60 Hz, 5-12 VDC via 2.5 mm barrel input voltage.Jumbo frame support: Up to 10240 bytes, MTBF: 250000 hours.Supports MDI/MDIX auto-crossover, cost-effective mounting and proven solution.Includes US power supply - 120-240 V/50-60 Hz, velcro strip, user manual.Meets RoHS, WEEE, UL, CE, FCC Class A standards.Comes with lifetime warranty

Convert and extend a Gigabit Ethernet connection up to 10km over single-mode SC fiber - Provides a cost-effective Ethernet copper to fiber or fiber to copper link - LFP mode on fiber/copper sides - Compact design and wall mountable with easy installation - SC connection (fiber) and RJ45 connection (copper) - Fiber to Ethernet Converter / Fiber to Copper Converter / Fiber optic media converter / Fiber to Ethernet Media Converter / Media converter fiber to Ethernet.Converts and extends a Gigabit fiber (1000 Mbps) network over single-mode fiber on 1000BASE-LX networks.Provides a cost-effective Ethernet to fiber/copper to fiber link.Supports a maximum distance of 10 km over single mode duplex fiber optic cable (SC connection).Compact design and wall mountable.Non-blocking full wire-speed forwarding rate.LED Indicators for simple Ethernet/fiber network link monitoring.1310 nm wavelength.Supports IEEE 802.1q Tag VLAN pass through.Convert and extend a Gigabit Ethernet connection up to 10 km over single-mode SC fiber

Omnitron miConverter miniature UTP to 100 fiber media converter provides cost-effective fiber connectivity from Ethernet switches to diagnostic equipment, desktop and laptop. Converter features 10/100Base-TX and 100Base-FX network technology..Interface/ports: 1 x RJ45, 1 ST port.Dimensions: 0.8"(H) x 1.7"(W) x 4.1"(D).Compatibility: PC.Connectivity technology: Wired.ST port type: Duplex.Form factor: External.Connectivity media: Twisted-pair, optical fiber.Max transfer distance: 3.11 mile.Ethernet technology: Fast Ethernet.Network technology: 10/100Base-TX, 100Base-FX.Wall-mount with optional mounting brackets, small and light, weighs only 5 ounces (without power supply).Input voltage: 15 VDC.Supports full/half-duplex UTP auto-negotiation.Multimode, single-mode and single-fiber options, ST or SC fiber connector options, optional USB power adapter cable available for operation without AC power adapter.Includes miConverter 10/100, US power supply 120volt / 60Hz, user manual.Certifications and standards: RoHS, WEEE, EIA/TIA 568A/B, UL, CE, FCC-Class B, IEEE 802.3, IEEE 802.3u.Warranty: Lifetime limited.Omnitron miConverter miniature UTP to 100 fiber media converter automatically adjusts crossover function and supports full/half-duplex UTP auto-negotiation.
