Gigabit SFP Modules

The Transition Networks® TN-GLC-SX-MM 1000Base-SX Gigabit Ethernet SFP transceiver module is suitable for Gigabit Ethernet switches and routers, fiber channel switch infrastructure, xDSL applications and metro edge switching. This hot pluggable transceiver module with LLC 1000Base-SX interface, transfers data at the rate of 1.25 Gbps up to 550 m distance over multi-mode fiber media at a wavelength of 850 nm. This transceiver module helps to install in any SFP port allowing for 1000Base-SX interface to the network through the SFP connector..Hot-pluggable SFP transceiver module is suitable for Gigabit Ethernet switches, routers, fiber channel switch infrastructure and xDSL applications.Dimensions: 0.33"H x 0.52"W x 2.18"D.Supports multi-mode fiber (MMF) connection media.Interfaces/ports: One LC 1000Base-SX.Ethernet technology: Gigabit Ethernet.Maximum data transfer rate: 1.25 Gbps.Reach: 550 m.Wavelength: 850 nm.Media type supported: Optical fiber.Link budget: 8.5 dB.Power: 3.3 V, Power consumption: 0.66 W.Temperature range: 0 - 70 deg C operating, 40 - 85 deg C storage.Fiber optic cable standard: 62.5/125 u m, 50/125 u m.SFP footprint LC optical transceiver.Has been designed to install in any SFP port while allowing for 1000Base-SX interface to the network through the SFP connector.Meets MSA, IEC-60825, FDA 21, CFR 1040.10 and 1040.11, IEEE 802.3 2003, ANSI X3.297-1977 certifications and standards.Comes with lifetime warranty

Industry standard Cisco small form factor pluggable (SFP) gigabit interface converter is a hot-swappable input/output device that plugs into a gigabit Ethernet port or slot, linking the port with the network..Interfaces/ports: 1 x LC duplex 1000Base-LX/LH.Dimensions: 0.3"(H) x 1/2"(W) x 2.2"(D).Compatibility: Cisco IE 3000 series switches, cisco 3200 series rugged routers, cisco MWR 2900 mobile wireless routers.Connectivity technology: Wired.Connectivity media: Single mode fiber 1000Base-LX/LH.Operating temperature: -40 - 185 deg F.Fiber type: SMF/MMF.Cabling type: Ethernet 1000Base-LX.Additional information: Spare product, range: 10 Km, wavelength: 1300 nm.Data transfer rate: 1 Gb/s gigabit Ethernet.Form factor: Hot swappable/plug-in.Application/usage: Data networking.SFP (mini-GBIC) transceiver module 1000 MBPS SFP single mode rugged 1000BASE-LX/LH SFP for MMF and SMF.

The Cisco™ GLC-TE= Gigabit Ethernet SFP transceiver module is suitable for 7700 F3-series, 9372PX and 9396PX Cisco Nexus series switches. This SFP transceiver module has RJ-45 1000Base-T network LAN ports for connectivity. It supports twisted pair media for reliable data transfer..SFP transceiver module for 7700 F3-series, 9372PX and 9396PX Cisco Nexus series switches.Color: Silver.Connectors: One RJ-45 1000Base-T network LAN.Media type supported: Twisted pair.Ethernet technology: Gigabit Ethernet

Cisco™ Downstream SFP module is a hot-swappable I/O device that plugs into a gigabit Ethernet slot and linking it with the fiber-optic network. Module supports data networking applications and offers data transfer rate of 1 Gb/s..1 x LC 1000Base-BX.0.3"(H) x 0.5"(W) x 2.2"(D).Cisco ME 2400, Catalyst 2960 series, Cisco ME 3400, Catalyst 3560 series, Catalyst 3750 series, Catalyst 4500 series, Catalyst 4900 series, Catalyst 6500 series.Wired.Connectivity media: G.652 microm single-mode optical fiber.Form factor: Hot-swappable.Management: Digital optical monitoring (DOM) functions, Application/usage: Data networking.Data transfer rate: 1 Gbps gigabit ethernet.Operating transmission range: Up to 10 km.Small form-factor pluggable (SFP) gigabit interface converter is a hot-swappable input/output device that plugs into a Gigabit Ethernet-port or slot, linking the-port with the network.1490-nm TX/1310-nm RX wavelength.Warranty: 90 days limited.Cisco™ Downstream SFP module has the ability to go up to 10 km over G.652 microm single-mode optical fiber and features digital optical monitoring functions.

To ensure that specifications are met over FDDI-grade, OM1 and OM2 fibers, the transmitter should be coupled through a mode conditioning patch cord. No mode conditioning patch cord is required for applications over OM3..SFP+ module is perfect for data networking, optical network.Dimensions: 0.3"H x 0.5"W x 2.2"D.Compatible with A9K-16T/8-B=, ME-3600X-24FS-M=, ME-3600X-24TS-M, N7K-F132XP-15=, N7K-M132XP-12L, WS-X45-SUP7-E/2 networking products.Interface/ports: 1 x LC duplex 10GBase-LRM network.Media type supported: Optical fiber, fiber mode supported: Multi-mode, single-mode, Ethernet technology: 10 Gigabit Ethernet.Maximum data transfer rate: 10 Gbps.Form factor: Hot-swappable, plug-in module.Up to 980', fiber optic cable standard: 62.5 ohm m, 50 ohm m, wavelength: 1300nm.Supports link lengths of 220m on standard fiber distributed data interface (FDDI) grade multimode fiber (MMF).Temperature range: 32 - 158 deg F.Transmit power: -6.5 to 0.5 dBm.Receive power: -8.4(in average) and -6.4 (in OMA) - 0.5 dBm.Connectivity media: 62.5 um, 50 um multi-mode fiber 10GBase-LRM, single-mode fiber 10GBase-LRM.Power consumption: 1 W.Core size: 62.5 - G.652 microns.Cable distance: 220 - 300 m.Cable type: MMF and SMF.Transmit and receive wave length: 1260 - 1355nm.Compliant standards: IEEE 802.3ae, IEC 60825-1, laser class 1.Warranty: 90 days limited.10GBase-LRM SFP transceiver module supports link lengths of 220 m on standard fiber distributed data interface (FDDI) grade multimode fiber (MMF).

Cisco™ 100Base-LX10 rugged SFP module has wavelength of 1310 nm and is compatible with Cisco™ IE 3000 series switches. Module is used in data networking and has single-mode optical fiber 100Base-LX10 media connectivity..Dimensions: 0.3"(H) x 0.5"(W) x 2.2"(D).For Cisco IE 3000 series switches.Hot-swappable when deployed, the switch or router does not have to reboot.Interfaces/ports: 1 x LC duplex 100Base-LX10.Application/usage: Data networking.Data transfer rate: 100 Mbps fast ethernet.Connectivity technology: Wired.Form factor: Hot-swappable.Connectivity media: Single-mode optical fiber 100Base-LX10.Wavelength: 1310 nm.Max transfer distance: 6.2 miles.Operating temperature: -40 - 185 deg F.Supports the Cisco quality ID feature that enables the switch or router to identify whether or not the SFP is a Cisco qualified SFP.Compliant and standards: IEEE 802.3, IEEE 802.3ah.Warranty: 90 days limited.Cisco™ 100Base-LX10 rugged SFP module operates on ordinary single-mode fiber-optic link that spans up to 10 km long and has hot-swappable form factor.

The Cisco multi-mode rugged SFP module adapts your switch or router, enabling you to connect long-range cables. As a result, you can extend the range of your network and expand connectivity. The SFP module is made with an intuitive design that is easy to install and use, so you can expand your network quickly and with minimum hassle..Interfaces/ports: 1 x LC duplex 100Base-FX.Dimensions: 0.33"(H) x 0.52"(W) x 2.22"(D).Compatibility: Cisco 100 m Ethernet SFP Compatibility matrix.Connectivity technology: Wired.Optical wave length: 1310 nm.Temperature: 122 deg F max operating.Compliant standards: IEEE 802.3, IEEE 802.3ah.Connectivity media: Multi mode fiber 100Base-FX.Max transfer distance: 1.2 miles.Data transfer rate: 100 Mbps fast ethernet.Form factor: Hot-swappable.90 days limited warranty.Cisco Multi-Mode Rugged SFP Module - Hot-Swap Capability

The Cisco 10GBASE-SR module supports link lengths up to 26m on standard Fiber Distributed Data Interface (FDDI) grade multimode fiber (MMF). Using 2000MHz x km of MMF (OM3), it is possible to create link lengths up to 300m, and with 4700MHz x km MMF (OM4), link lengths up to 400m are possible..Multimode fiber optic transceiver with dual LC/PC connector.10GBASE SFP+ module for data center, enterprise wiring closet, and service provider transport applications.Provides data transfer rates up to 10Gbps.Supports link lengths up to 26m on standard FDDI-grade MMF; up to 300m on 2000MHz x km MMF (OM3); and up to 400m on 4700MHz x km MMF (OM4).Power consumption: 1W.Hot-swappable, plugs into an Ethernet SFP+ port.Compliant with the SFP+ MSA SFF-8431 standard.Wavelength: 850nm.Form factor: Hot-swappable.MSA compliant.Commercial temperature: 32 to 158 degrees Fahrenheit.Supports digital optical monitoring capability.Optical interoperability with 10GBASE XENPAK, 10GBASE X2, and 10GBASE XFP interfaces on the same link.1-year manufacturer limited warranty

The Cisco transceiver module has one LC duplex 10GBase-LR port, and it is compatible with the Alcatel-Lucent Omniswitch 6900, making it easy to install and use with your system. The piece is hot swappable and allows you to select the interface of your choice for flexibility. It is the smallest 10G form factor, so it saves you space..Interfaces/ports: 1 x LC duplex 10GBase-LR.Dimensions: 0.3"(H) x 1/2"(W) x 2.2"(D).Compatibility: Alcatel-lucent omniswitch 6900.Smallest 10G form factor.Supports 10GBASE Ethernet and OTU2/OTU2e.Hot-swappable input/output device that plugs into an Ethernet SFP+ port of a Cisco switch.Provides flexibility of interface choice.Optical interoperability with 10GBASE XENPAK, 10GBASE X2, and 10GBASE XFP interfaces on the same link.Supports "pay-as-you-populate" model.Supports digital optical monitoring capability.Supports the cisco quality identification (ID) feature that enables a Cisco switch to identify whether the module is certified and tested by Cisco.Form factor: Hot-swappable.Cisco Transceiver Module - Switch Accessories for Networking

Omnitron Pluggable optical transceiver operates at 850 nm wavelength and covers a maximum distance of up to 1800'. Transceiver is compatible with iConverter media converter modules, T1/E1 MUXes and network interface devices..Interfaces/ports: 1 x LC 1000Base-SX.Connectivity media: Multi-mode optical fiber.Ethernet technology: Gigabit Ethernet.Form factor: Plug-in module.Data rate: 1 Gbps.Cable distance: 550 meters.Wavelength: 850 nm.Application/usage: Data networking.Connectivity technology: Wired, Min. Tx Power (dBm): -9.5, Max. Tx Power (dBm): -4,Min. Rx Sense (dBm): -17, Max. Rx Power (dBm): -3, Link budget (dBm): 7.5.Low EMI metal enclosure, supports a wide variety of cable types.Digital diagnostic capability.Pluggable optical transceivers enable flexible fiber and copper connectivity.Warranty: Lifetime.Omnitron Pluggable optical transceiver transfers data at a rate of 1 Gb/s and enables a single network device to connect to a wide variety of fiber optic cable types.

AddOn® 1000BASE-LX 1310nm 10km SMF SFP Module is built to meet or exceed the OEM's specifications and supports optical networking. Module can be deployed with 3rd party transceivers for seamless network performance and features SMF connectivity..Interface/ports: 1 x LC 1000Base-LX/LH network.Compatibility: Catalyst Express 500, Catalyst Express 520, ME 3400, ME 3600X, ME 3800X, ME 4900 Series, Catalyst 2940, 2950, 2960, 2960-S, 2960-C, 2970, 2975, 3560, 3560-E, 3560-X, 3560-C, 3750, 3750-E, 3750-X Series.Connectivity technology: Wired.Form factor: Hot-swappable.Connectivity media: Single-mode optical fiber 1000Base-LX/LH, multi-mode optical fiber 1000Base-LX/LH.Max transfer distance: 10km.Data transfer rate: 1 Gbps gigabit Ethernet.1310 nm wavelength.SFP module is a Cisco compatible SFP transceiver that operates at 1310nm over single-mode fiber, with a maximum reach of 10km connected via a LC connector, built to meet or exceed the OEM's specifications, and comply with MSA.Hot-swappable input/output device that plugs into a gigabit Ethernet slot, linking the port with the fiber-optic network.Warranty: Lifetime limited.AddOn® 1000BASE-LX 1310nm 10km SMF SFP Module is supported with DOM to access real-time operating parameters and is hot swappable.

The Cisco 10GBASE-SR module supports link lengths up to 26m on standard Fiber Distributed Data Interface (FDDI) grade multimode fiber (MMF). Using 2000MHz x km of MMF (OM3), it is possible to create link lengths up to 300m, and with 4700MHz x km MMF (OM4), link lengths up to 400m are possible..Multimode fiber optic transceiver with dual LC/PC connector.10GBASE SFP+ module for data center, enterprise wiring closet, and service provider transport applications.Provides data transfer rates up to 10Gbps.Supports link lengths up to 26m on standard FDDI-grade MMF; up to 300m on 2000MHz x km MMF (OM3); and up to 400m on 4700MHz x km MMF (OM4).Power consumption: 1W.Hot-swappable, plugs into an Ethernet SFP+ port.Compliant with the SFP+ MSA SFF-8431 standard.Wavelength: 850nm.Form factor: Hot-swappable.MSA compliant.Commercial temperature: 32 to 158 degrees Fahrenheit.Supports digital optical monitoring capability.Optical interoperability with 10GBASE XENPAK, 10GBASE X2, and 10GBASE XFP interfaces on the same link.1-year manufacturer limited warranty

It installs in a Mini-GBIC compliant slot and features a duplex LC connector that is compatible with 850nm multi-mode fiber cables..Type of Product/Use: Transceiver.Dimensions/Size: 2.2 x 0.5 x 0.3 inch.True color: Silver.850nm Wavelength for Multi-Mode Fiber.Connectivity media: 62.5/125 microm multi-mode optical fiber, 50/125 microm multi-mode optical fiber.Max transfer distance: 721.78 ft 62.5/125 microm, 902.23 ft 62.5/125 microm, 1640.42 ft 50/125 microm, 1804.46 ft 50/125 microm optical fiber.Data transfer rate: 1 Gbps gigabit-ethernet.Transmitter spec: Power: -9.5 to -4 dBm, Receiver spec: sensitivity: -20 to -17dBm, Input power: -20 to -17 dBm.Stress sensitivity: 50/125 um: -13.5 dBm, 62.5/125 um: -12.5 dBm, Wavelength: 850 nm (850nm TYP., 830-860nm) MMF.Environmental condition: Operating temperature: 32 - 104 deg F, Storage temperature: -4 -158 deg F Operating humidity: 0% to 85% non-condensing.Modular bandwidth for MMF: 62.5/125um MMF at 160 MHz/km, up to 220m, 62.5/125um MMF at 200 MHz/km, up to 275m, 50/125um MMF at 400 MHz/km, up to 500m, 50/125um MMF at 500 MHz/km, up to 550m.Provides a simple way to add Gigabit functionality to your Linksys switch.Gigabit fiber is often-used to connect two switches together.Technology used depends on the distance between the two switches.SX module uses 850 nanometer wavelength light in multimode fiber-optic cables, and can achieve distances up to 220 or 550 meters, depending on the fiber used.The Gigabit Ethernet SX Mini-GBIC SFP Transceiver from Cisco is an expansion module that adds high-density fiber connectivity to compatible devices.

It installs in a Mini-GBIC compliant slot and features a duplex LC connector that is compatible with 850nm multi-mode fiber cables..Type of Product/Use: Transceiver.Dimensions/Size: 2.2 x 0.5 x 0.3 inch.True color: Silver.850nm Wavelength for Multi-Mode Fiber.The Gigabit Ethernet SX Mini-GBIC SFP Transceiver from Cisco is an expansion module that adds high-density fiber connectivity to compatible devices.

The Omnitron 01-01-7207 SFP optical transceiver enables a single network device to connect to a wide variety of flexible fiber and copper cable through its interchangeable, compact media connectors. It is compatible with iConverter®, FlexPoint™, OmniConverter™ and miConverter™ products to meet specific network protocols and media requirements. This transceiver supports digital diagnostic by providing enhanced diagnostic information. The compact design and the ease of interchangeability of this unit provide a flexible solution for network designs..Optical transceiver module is compatible with iConverter media converter modules, T1/E1 multiplexers and network interface devices.LC duplex 1000Base-LX network.Media type supported: Optical fiber, fiber mode supported: Single-mode, fiber optic cable standard: 9/125 ohm m.Form factor: Hot-pluggable, hot-swappable, data transfer rate: 1.25 Gbps.Compatible with FlexPoint, OmniConverter and miConverter media converter modules that support SFP transceivers.Compliant with IEEE 802.3u fast Ethernet and 802.3z gigabit Ethernet specifications.Supports operational data rates for SONET OC-3/12/48, SDH STM-1/4/16 and fiber channel x1/x2.Supports a wide variety of cable types, supports digital diagnostic capability, low EMI metal enclosure.Temperature: 0 to 50 deg C commercial, -40 to 80 deg C storage.Meets RoHS, Green, WEEE standards.Comes with 1 year warranty.Certifications and standards: Compliant with MSA SFF-8472 standard.OMNITRON SYSTEMS iConverter 1000Base-LX SFP Optical transceiver supports data transfer rate of 1 Gb/s and is suitable to use with networking applications.

Cisco 1000BASE-LX SFP (mini-GBIC) Transceiver easy-to-install module that provide a simple way to add fiber connectivity or to add an extra Gigabit Ethernet port to your Cisco Small Business or Cisco Small Business Pro Series switches. The transceiver available for single-mode fiber-optic cabling and can support distance up to 10 kilometers..Type of Product/Use: Transceiver.Dimensions/Size: 0.5 x 0.3 x 2.2 inch.True color: Silver.1000Base-LX.1 x LC Duplex Connector.Single-Mode Fiber (SMF).10 km (6.2 miles) Max..1000 Mbps Transfer Rate.The MGBLX1 SFP Transceiver from Cisco is an easy-to-install module that provides a simple way to add an extra Gigabit Ethernet port to your Cisco Small Business or Cisco Small Business Pro Series switches.
