UniFi PoE Injectors

Ubiquiti™ Networks™ 48 VDC 24 W Power over Ethernet injector with gigabit LAN port features RJ-45 input/output port to deliver high-speed internet. Injector comes with USA power cord and features an LED display to indicate status of power..Frequency: 47 - 63 Hz, 65 kHz switching.Dimensions: 1.3"(H) x 3.61"(W) x 2.36"(D).Interfaces/ports: Input ports: 1 x RJ-45 ethernet, output ports: 1 x RJ-45 ethernet.Power: Output power: 24 W, input voltage: 110 - 220 VAC, 48 VDC output, input current: 600 mA at 110 VAC, 400 mA at 220 VAC, 500 mA output.Efficiency: 80+%, output ripple: 1%, regulation: + or - 1% line, + or - 3% load, peak pulse current: 36A (10/1000microsecond) data.Operating temperature: -10 - +60 deg C, Operating humidity: 5 - 90% non condensing.Surge protection: Difference and common mode, clamping protection: 11 V data, 60 V power.Shunt capacitance: <5 pf data, response time: <1 nS, 2-pair powering: Pins 4, 5 (+) and pins 7, 8 (-).Compatibility: Rocket-Ti, UAP-Pro.Certifications and standards: IEC 60950-1:2005+A1, UL60950-1, EN55022:2010, EN55024:2010, FCC Class B.Weight: 5.59 oz..Ubiquiti™ Networks™ 48 VDC 24 W Power over Ethernet injector with gigabit LAN port provides earth grounding/surge protection and also helps to protect against ESD attacks.

Ubiquiti UniFi Switch Pro 48 PoE is a fully managed Layer 3 switch with eight 802.3bt (PoE++) and 40 802.3at (PoE+) Gigabit Ethernet ports. Four 10G SFP+ uplinks offer link aggregation for higher capacity and increased availability. The UniFi Pro features a rich set of Layer 2 capabilities and integrates Layer 3 functionality such as inter-VLAN routing, static routing, and DHCP server. The UniFi Pro is the perfect access layer switch for any UniFi solution – it combines up to 600W of near-silent PoE power with UniFi SmartPower RPS power redundancy. UniFi Network Controller and UniFi Network mobile app allow admins to configure and monitor virtually all of the switch features in an intuitive graphical user interface from anywhere..Fully managed Layer 3 switch with eight 802.3bt (PoE++) and 40 802.3at (PoE+) Gigabit Ethernet ports.Contains eight Gigabit RJ45 802.3bt PoE++ ports, 40 Gigabit RJ45 802.3at PoE+ ports, four 10G SFP+ ports.UniFi Network Controller and UniFi Network mobile app allow admins to configure and monitor virtually all the switch features in an intuitive graphical user interface from anywhere.Dimensions: 1.72"H x 17.42"W x 15.73"D.Max. power consumption (excluding PoE output): 60W.Certifications and standards: Meets or exceeds CE, FCC, IC standards.In addition to Layer 2 switching protocols and features, offers Layer 3 capabilities, such as inter‑VLAN routing, static routing, and DHCP server functionality.Can be located in any workspace; its integrated fans have built-in PWM (power management) control, air ducts and covers, and temperature sensors for the best user experience.SFP+ ports enable high-capacity uplinks of up to 10Gbps, so you can directly connect to a high-performance storage server or deploy a long-distance uplink to another switch.1.3" touch screen displays status information for easy monitoring and quick troubleshooting.Comes in silver.2-year manufacturer limited warranty

Ubiquiti PoE Injector.Input Voltage: 24 V DC.Form Factor: Desktop.Maximum Output Power: 24 W

The Ubiquiti® POE-24-24W-G 24 V gigabit PoE injector offers surge protection, clamping protection, maximum surge discharge and peak pulse current for PoE devices protection. It supports Gigabit LAN PoE interface..Gigabit PoE injector offers earth grounding and surge protection to help protect against electrostatic discharge events.Dimensions: 2.24"H x 3.47"W x 1.3"D.Power: 24 VDC/1 A, 90 - 260 VAC at 47 - 63 Hz (input), Current: 0.6 A at 120 VAC, 0.4 A at 240 VAC (input).Frequency: 65 kHz (switching).Interface/ports: Gigabit LAN PoE.Efficiency: 80+ percent, Output ripple: 1 percent, Line regulation: + 1 percent, Load regulation: + 3 percent.4-Pair powering: Pins 1, 2, 4, 5 (+) and pins 7, 8, 3, 6 (-), AC connector: IEC-320 C6, Data In/PoE: RJ-45 shielded socket.Surge discharge: 1500 A power, Shunt capacitance: <5 pf data, Response time: <1 nS.Meets IEC 60950-1:2005+A1, UL60950-1, EN55022:2010, EN55024:2010, FCC Class B certifications and standards

Ubiquiti UniFi Switch Lite 16 PoE is a fully managed Layer 2 switch with sixteen Gigabit Ethernet ports for your RJ45 Ethernet devices. Eight ports also offer auto-sensing 802.3at PoE+ that provide up to a total PoE wattage of 45W for UniFi Access Points or other PoE devices. Managed and configured by the UniFi Network application with UniFi mobile app support, the UniFi Switch Lite 16 PoE offers Layer 2 switching protocols and features. The UniFi Network Controller and mobile app allow admins to configure and monitor virtually all of the switch features in a graphical user interface from anywhere..Fully managed layer 2 switch with 16 Gigabit Ethernet ports for your RJ45 Ethernet devices.Dimensions: 1.72"H x 7.55"W x 7.28"D.Comes in white.16 Gigabit RJ45 ports including eight 802.3at PoE+.Managed with UniFi application.60W power supply.Wall-mountable (kit included)

Build and expand your network with the Ubiquiti UniFi Flex switch, part of the UniFi Enterprise System. The UniFi switch is a configurable Layer 2 Gigabit switch with auto-sensing 802.3af PoE. It offers 5 RJ45 Gigabit Ethernet ports, providing 1 PoE input and 4 PoE output links to your devices. The Ubiquiti UniFi Flex features a single PoE In port for power and four PoE ports that provide up to 15W PoE output to power a UniFi access point or other PoE devices. With 802.3bt rated PoE switches (USW-Pro-48-PoE, USW-Pro-24-PoE, US-XG-6POE, and USW-Industrial switches, sold separately) as power source, USW-Flex supports maximum 46W PoE output budget. It has weatherproof housing and offers versatile mounting options. Managed and configured by the UniFi Controller or UniFi Mobile app, the Ubiquiti UniFi Flex switch offers basic Layer 2 switching protocols and features. The UniFi Controller and mobile app allow admins to configure and monitor virtually all of the switch features using a graphical user interface from anywhere..Managed switch is a configurable Layer 2 Gigabit switch with auto-sensing 802.3af PoE.Features 5 x Gigabit RJ45 ports to deliver robust performance and intelligent switching for your network; port 1 provides PoE input while ports 2-4 offer 802.3af PoE.Managed and configured by the UniFi Controller or UniFi Mobile app, switch offers basic Layer 2 switching protocols and features.Can be installed horizontally or vertically and offers versatile mounting options: desktop, wall, and pole.Offers the forwarding capacity to simultaneously process traffic on all ports at line rate without any packet loss.Maximum power consumption: 5W (excluding PoE output).Meets or exceeds the CE, FCC, IC standards.Weather-resistant switch can withstand extreme temperature variations.Supports up to 5Gbps of total non-blocking throughput.Dimensions: 4.66"H x 2.48"W x 1.36"D.1-year manufacturer limited warranty

The Ubiquiti Switch Enterprise has a 124 Gb/s with 62 Gb/s non-blocking throughput and a 92.25 Mpps forwarding rate for smooth data transfers..(12) 2.5 GbE, (12) GbE; all PoE+ ports.(2) 10G SFP+ ports.400W total PoE availability.DC power backup-ready.Layer 3 switching.Remote firmware upgrade.Manage your networks from a single control panel

A 48-port, Layer 3 Etherlighting™ switch with 2.5 GbE and PoE++ output..48-port, Layer 3 Etherlighting switch with 2.5 GbE and PoE++ output.Supports Power over Ethernet.Offers 166.66Mpps forwarding rate, 224Gbps switching capacity, and 112Gbps total non-blocking throughput.Rack-mountable.Managed with UniFi Network 8.0.24 and later.Maximum power consumption: 100W (excluding PoE output).Contains 16 2.5 GbE ports including eight PoE+ and eight PoE++, 32 GbE ports including 24 PoE+ and eight PoE++, four 10G SFP+ ports.Etherlighting ports that illuminate to indicate port location, speed/link, and native VLAN/network.1.3" touch-screen LCM display for convenient use.Provides 720W total PoE availability.DC power backup ready.Meets or exceeds CE, FCC, IC standards

The Ubiquiti Instant INS-3AF-I-G indoor Gigabit PoE converter for 802.3af switches, transforms any Ubiquiti PoE devices into a fully compliant 802.3af compatible product. It works with 10/100/1000 Mbps ports to deliver high throughput speeds over a wired connection. This instant 802.3af adapter supports longer cable runs for more efficient power delivery. The device provides an additional +/-15 kV of Ethernet isolation for built-in protection or surge protection. It is compatible with airMAX and UniFi devices..Indoor Gigabit PoE converter transforms passive PoE devices into 802.3af-compliant products.Dimensions: 3.76"D x 1.19"Dia. (with RJ45 cable).Compatibility: 802.3af switches for remote control power applications.Protection type: Surge protection.Interfaces/ports: 1 x Gigabit RJ45 port (PoE in), 1 x Gigabit RJ45 port (PoE out).Network and communication: 10/100/1000Base-T.Power: 48 VDC input, 24 V, 0.5 A output.Form factor: External.Enables longer cable runs due to a more efficient power delivery.Provides an additional +/- 15 kV of Ethernet isolation to lessen the risk of ESD or surge damage to connected devices.Weight: 1.76 oz.

Create your own LAN and connect your PC, laptop, printer and other peripherals with the help of 4 ports..Supports cost-efficient twisted pair cables for high-speed data transfer up to 100 meters.Optimize the performance of business networks with 10 Gigabit Ethernet connectivity.Layer 2 switch provides a complete lineup of features including IGMP snooping, port mirroring, and spanning tree.Managed switch provides a reliable foundation for your network

Ubiquiti UniFi Pro is a fully managed Layer 3 switch with eight 802.3bt (PoE++) and 16 802.3at (PoE+) Gigabit Ethernet ports. Two 10G SFP+ uplinks offer link aggregation for higher capacity and increased availability. The UniFi Pro features a rich set of Layer 2 capabilities and integrates Layer 3 functionality such as inter-VLAN routing, static routing, and DHCP server. The UniFi Pro is the perfect access layer switch for any UniFi solution it combines up to 400W of near-silent PoE power with UniFi SmartPower RPS power redundancy. UniFi Network Controller and UniFi Network mobile app allow admins to configure and monitor virtually all of the switch features in an intuitive graphical user interface from anywhere..Fully managed Layer 3 switch with eight 802.3bt (PoE++) and 16 802.3at (PoE+) Gigabit Ethernet ports.Contains eight Gigabit RJ45 802.3bt PoE++ ports, 16 Gigabit RJ45 802.3at PoE+ ports, two 10G SFP+ ports.UniFi Network Controller and UniFi Network mobile app allow admins to configure and monitor virtually all the switch features in an intuitive graphical user interface from anywhere.Dimensions: 1.72"H x 17.42"W x 11.24"D.Max. power consumption (excluding PoE output): 50W.Certifications and standards: Meets or exceeds CE, FCC, IC standards.In addition to Layer 2 switching protocols and features, offers Layer 3 capabilities, such as inter‑VLAN routing, static routing, and DHCP server functionality.Can be located in any workspace; its integrated fans have built-in PWM (power management) control, air ducts and covers, and temperature sensors for the best user experience.SFP+ ports enable high-capacity uplinks of up to 10Gbps, so you can directly connect to a high-performance storage server or deploy a long-distance uplink to another switch.1.3" touch screen displays status information for easy monitoring and quick troubleshooting

Expand your network with the Ubiquiti eight-port layer 2 PoE switch supporting silent fanless cooling. Features four GbE, PoE+ RJ45 ports and four GbE RJ45 ports. Managed with the UniFi Network application: version 7.2.94 and late..Compact eight-port layer 2 PoE switch supporting silent fanless cooling.Features 4 x RJ45 (GbE, PoE+) ports and 4 x RJ45 (GbE) ports.Total non-blocking line rate: 8Gbps.Max power consumption: 8W.Meets or exceeds CE, FCC, IC standards.Power adapter included (54VDC, 1.1A).Maximum PoE+ wattage per port by PSE: 30W.Dimensions: 1.25"H x 6.44"W x 3.92"D.Managed with the UniFi Network application (version 7.2.94 and later).Wall-mountable (kit is included)

Expand your network with the UniFi Flex Mini switch, part of the Ubiquiti UniFi Enterprise system. The cost-effective UniFi Switch Flex Mini can be discreetly integrated into any environment. Five RJ45 ports offer 10/100/1000 links. One port also supports 802.3af/at PoE input. The UniFi Flex Mini switch offers the forwarding capacity to simultaneously process traffic on all ports at line rate without any packet loss..Compact five-port layer 2 switch that can be powered with PoE or a USB Type-C adapter (5V).Five RJ45 ports offer 10/100/1000 links; one port also supports 802.3af/at PoE input.Forwarding rate: 7.44Mpps; switching capacity: 10Gbps.Offers the forwarding capacity to simultaneously process traffic on all ports at line rate without any packet loss.Uses only 2.5W and can be powered by 802.3af/at PoE or a USB Type-C power adapter (5V, 1A).Meets or exceeds CE, FCC, IC standards.Dimensions: 0.83"H x 4.22"W x 2.76"D.Managed with the UniFi Network application (version 5.12.5 and later)

Ubiquiti UniFi is a configurable Gigabit Layer 2 switch with twenty-four Gigabit Ethernet ports including sixteen auto-sensing 802.3at PoE+ ports, and two SFP ports. It provides Gigabit PoE links to your RJ45 Ethernet devices and Gigabit fiber uplink options to your enterprise network. Features a 1.3" touch LCM to provide status information. With a depth of 7.9", the compact fanless design can be easily installed in a SOHO rack cabinet. Managed and configured by the UniFi Network Controller with UniFi mobile app support, the switch offers an extensive suite of advanced Layer 2 switching protocols and features, including operation mode (switching, mirroring, or aggregate) per port. The UniFi Network Controller and mobile app allow admins to configure and monitor virtually all of the switch features in a graphical user interface from anywhere. FP ports enable network uplinks of up to 1 Gbps. The UniFi PoE Switch features fanless, silent thermal cooling, so it can be located in any workspace..Configurable Gigabit Layer 2 switch with 24 Gigabit Ethernet ports including 16 auto-sensing 802.3at PoE+ ports, and two SFP ports.Contains 24 10/100/1000 RJ45 ports and two 1G SFP Ethernet ports.Managed and configured by the UniFi Network Controller with UniFi mobile app support, the switch offers an extensive suite of advanced Layer 2 switching protocols and features.Dimensions: 1.72"H x 16.71"W x 7.87"D.Max. power consumption (excluding PoE output): 18W.Certifications and standards: Meets or exceeds CE, FCC, IC standards.1.3" touch screen displays status information for easy monitoring and quick troubleshooting.Quiet cooling for any workspace.SFP ports enable network uplinks of up to 1 Gbps.Features fanless, silent thermal cooling, so it can be deployed in areas where fan noise would be distracting..Offers the forwarding capacity to simultaneously process traffic on all ports at line rate without any packet loss.Comes in silver.2-year manufacturer limited warranty

Expand and power your network with the UniFi PoE switch, part of the Ubiquiti UniFi Enterprise System. The UniFi PoE switch features fanless, silent thermal cooling, so it can be deployed in areas where fan noise would be distracting..This smart switch contains 32 x Gigabit RJ45 ports with 802.3af/at, 16 x Gigabit RJ45 ports, and 4 x 1G SFP ports.PoE support simplifies your network infrastructure and cabling; PoE ports offer 802.3af/at to power your PoE devices, such as UniFi APs and cameras.Provides up to 104Gbps of switching capacity.Rack-mountable for convenient use.UniFi Network Controller can provision UniFi devices, map out networks, and quickly manage system traffic. Important network details are logically organized for a simplified, yet powerful, interface.Maximum power consumption: 45W.Meets or exceeds CE, FCC, IC standards.Offers the forwarding capacity to simultaneously process traffic on all ports at line rate without any packet loss.SFP ports enable network uplinks up to 1Gbps.Features a 1.3" LCM color touch screen with AR switch management.2-year manufacturer limited warranty

The Ubiquiti EdgePoint PoE injector provides a variety of features to help protect your PoE devices: surge protection, clamping protection, maximum surge discharge, peak pulse current, AC cable with earth ground..PoE injector with a variety of features to help protect your PoE devices.Compatible with airFiber, airMAX, EdgeMAX, mFi, UniFi AP, UniFi Protect, airVision, UniFi LED, UFiber.Dimensions: 1.34"H x 4.84"W x 2.56"D.Comes in white.Offers 80W of power to an Ethernet cable for PoE devices.Contains 1 x Gigabit Ethernet RJ45 LAN and 1 x PoE ports.Output voltage: 54VDC/1.5A.Rated voltage: 100-240VAC, 50/60Hz.Surge protection: difference and common Mode.Meets or exceeds the CE, FCC, IC and UL standards
