48V PoE Injectors

The Ubiquiti® POE-24-24W-G 24 V gigabit PoE injector offers surge protection, clamping protection, maximum surge discharge and peak pulse current for PoE devices protection. It supports Gigabit LAN PoE interface..Gigabit PoE injector offers earth grounding and surge protection to help protect against electrostatic discharge events.Dimensions: 2.24"H x 3.47"W x 1.3"D.Power: 24 VDC/1 A, 90 - 260 VAC at 47 - 63 Hz (input), Current: 0.6 A at 120 VAC, 0.4 A at 240 VAC (input).Frequency: 65 kHz (switching).Interface/ports: Gigabit LAN PoE.Efficiency: 80+ percent, Output ripple: 1 percent, Line regulation: + 1 percent, Load regulation: + 3 percent.4-Pair powering: Pins 1, 2, 4, 5 (+) and pins 7, 8, 3, 6 (-), AC connector: IEC-320 C6, Data In/PoE: RJ-45 shielded socket.Surge discharge: 1500 A power, Shunt capacitance: <5 pf data, Response time: <1 nS.Meets IEC 60950-1:2005+A1, UL60950-1, EN55022:2010, EN55024:2010, FCC Class B certifications and standards

Maximum Output Power: 30 W.Form Factor: Desktop.Input Voltage: 24 V DC

The Ubiquiti Networks PoE Injector is designed for the company's airFiber, airMAX, EdgeMAX, mFi, UniFi AP, and UniFi Protect / airVision products. This 24 VDC, 7.2W, 0.3A adapter provides protection against surge, clamping, maximum surge discharge, and peak pulse current..Ubiquiti Networks offers Power over Ethernet (PoE) Adapters to power a variety of Ubiquiti products. The PoE Adapters are compatible with most Ubiquiti PoE devices, including: airFiber®, airMAX®, EdgeMAX®, mFi®, UniFi® AP, UniFi Video / airVision®.Specific PoE Adapter models are designed to work with the airGateway. The airGateway is a compact CPE (consumer premises equipment) gateway with built-in Wi-Fi used to connect the subscriber's local network to the WISP network..120 V AC, 230 V AC Input - 24 V DC, 300 mA Output.Gigabit Ethernet Input Port(s) - Gigabit Ethernet Output Port(s).Ubiquiti Networks PoE Injector (24 VDC, 7.2W)

Ubiquiti PoE Injector.Input Voltage: 24 V DC.Form Factor: Desktop.Maximum Output Power: 24 W

The Ubiquiti® POE-24-12W-G 24V PoE injector with Gigabit LAN port, powers a variety of PoE devices belonging to the airFiber, airMAX, EdgeMAX, airVision, UniFi and mFi series. This 24 VDC injector provides protection against surge, clamping, peak pulse current, maximum surge discharge and ESD attacks..Power over Ethernet injector provides protection against surge, clamping, peak pulse current.Compatible with Ubiquiti products - airFiber, airMAX, airVision, UniFi, mFi.Interface/ports: Gigabit LAN port.Dimensions: 1.14"H x 3.43"W x 1.73"D.Form factor: Wall mountable.Power supply: Input: 90 - 260 VAC at 47 - 63 Hz, 0.3 A at 120 VAC, 0.2 A at 240 VAC, output: 24 VDC at 0.5 A.Temperature: 0 - 40 deg C operating, -30 - 70 deg C storage, humidity: 35 - 95% non-condensing operating.Meets IEC 60950-1:2005+A1, UL60950-1, EN55022:2010, EN55024:2010, FCC Class B, USA, EU, AR, BR, UL, CCC, Mexico standards.Weight: 3.51 oz.

Sends data and power over a single Ethernet cable Use to power IP phones, security cameras, wireless access points, IP print servers, and other 802.3af-compatible equipment Avoid the cost and hassle of installing AC power at a remote camera or door scanner Supports 10/100/1000-Mbps midspan data connections on RJ-45 input/output Protection includes overvoltage/current overload and short circuit protection on the power output (per 802.3af specifications) Diagnostic LED indicates adverse power conditions Detects unstable current measurements, low voltage, incorrect resistive signature, and more Simple plug-and-play installation Compact, weighs less than half a pound and can be easily wall-mounted RoHS compliant The device has Data In RJ-45 (10/100/1000) and Data/PoE Out RJ-45 (10/100/1000). PoE midspan injectors are used in Enterprise applications to power VoIP phones, wireless access points, IP security cameras and more. PoE injectors add power to the Ethernet link and avoid upgrading switch infrastructure. PoE enables you to avoid installing AC power at a remote powered device. This device is designed for desktop or panel mounting and includes a 100-240VAC internal power supply delivering 15W per port..Provides 15 W of safe Power over Ethernet (PoE) Plus power to each device.Supports Gigabit Ethernet data connections for high-speed equipment.Provides overvoltage and overcurrent overload protection as well as short circuit protection on the power output (per 802.3af specifications).Over temperature protection. Shuts down automatically without being damaged

An Instant PoE adapter designed for indoor use that transforms almost any Ubiquiti PoE (Power over Ethernet) device into a fully compliant 48V, PoE-compatible product. The Instant PoE Adapter also provides an additional ±15kV of Ethernet isolation for built-in protection that lessens the risk of ESD or surge damage to your devices..This PoE adapter designed for indoor use transforms almost any Ubiquiti PoE (Power over Ethernet) device into a fully compliant 48V PoE compatible product.Dimensions: 3.68"H x 1.06"W x 0.85"D.Provides an additional ±15kV of Ethernet isolation for built-in protection that lessens the risk of ESD or surge damage to your devices

Ubiquiti UniFi Switch Pro 48 PoE is a fully managed Layer 3 switch with eight 802.3bt (PoE++) and 40 802.3at (PoE+) Gigabit Ethernet ports. Four 10G SFP+ uplinks offer link aggregation for higher capacity and increased availability. The UniFi Pro features a rich set of Layer 2 capabilities and integrates Layer 3 functionality such as inter-VLAN routing, static routing, and DHCP server. The UniFi Pro is the perfect access layer switch for any UniFi solution – it combines up to 600W of near-silent PoE power with UniFi SmartPower RPS power redundancy. UniFi Network Controller and UniFi Network mobile app allow admins to configure and monitor virtually all of the switch features in an intuitive graphical user interface from anywhere..Fully managed Layer 3 switch with eight 802.3bt (PoE++) and 40 802.3at (PoE+) Gigabit Ethernet ports.Contains eight Gigabit RJ45 802.3bt PoE++ ports, 40 Gigabit RJ45 802.3at PoE+ ports, four 10G SFP+ ports.UniFi Network Controller and UniFi Network mobile app allow admins to configure and monitor virtually all the switch features in an intuitive graphical user interface from anywhere.Dimensions: 1.72"H x 17.42"W x 15.73"D.Max. power consumption (excluding PoE output): 60W.Certifications and standards: Meets or exceeds CE, FCC, IC standards.In addition to Layer 2 switching protocols and features, offers Layer 3 capabilities, such as inter‑VLAN routing, static routing, and DHCP server functionality.Can be located in any workspace; its integrated fans have built-in PWM (power management) control, air ducts and covers, and temperature sensors for the best user experience.SFP+ ports enable high-capacity uplinks of up to 10Gbps, so you can directly connect to a high-performance storage server or deploy a long-distance uplink to another switch.1.3" touch screen displays status information for easy monitoring and quick troubleshooting.Comes in silver.2-year manufacturer limited warranty

TRENDnet's 65W 4-Port Gigabit PoE+ Injector, model TPE-147GI, allows users to add PoE+ power to a non-PoE switch. Connect the 4-port PoE+ injector to a non-PoE Gigabit switch, and then run Ethernet cables up to 100 meters (328 ft.) to network four PoE devices. This multi-port gigabit PoE+ injector supplies up to 30W of power to four PoE or PoE+ devices. The fanless design on the 4-port PoE+ injector conveniently eliminates operating noise and lowers energy consumption. GIGABIT PORTS: 4 x gigabit ports (data in) and 4 x gigabit PoE ports (data + PoE out). EASY INSTALLATION: No configuration needed, simply connect a PoE network devices to this 4-port PoE+ injector 4-PORT POE: TRENDnet's 65W 4-Port Gigabit PoE+ Injector supplies up to 30W of power to four PoE (IEEE 802.3af) or PoE+ (IEEE 802.3at) devices at industry PoE standards for greater device interoperability POE DISTANCE: The multi-port gigabit PoE+ injector provides four PoE network connections up to 100m (328 ft.) away from the 4-port PoE injector FANLESS DISTANCE: The fanless design of the gigabit PoE+ Injector eliminates operating noise and lowers energy consumption. TRENDnet MANUFACTURER WARRANTY: TRENDnet backs this product with a 3-Year Manufacturer Warranty. NDAA / TAA compliant (U.S. and Canada only). More from the Manufacturer.4 x Gigabit PoE+ ports (Data + PoE out).65W PoE power budget.Supports both PoE (15.4W) and PoE+ (30W) power.Uses IEEE 802.3af / IEEE 802.3at industry PoE standards for greater device interoperability

TRENDnet's TI-IG90 is a reliable IP50 rated Industrial Gigabit PoE++ Injector with hardened components rated for extreme and rugged industrial environments. Connect the TI-IG90 industrial PoE injector to a non-PoE gigabit switch, and then run an Ethernet cable up to 100 meters (328 ft.) to network a PoE device. The TI-IG90 industrial PoE injector supplies power to a PoE, PoE+, or PoE++ (up to 95W) device. This industrial PoE injector features dual redundant power inputs with overload current protection to support zero downtime applications. Both DIN-rail and wall mount hardware are included with the industrial PoE injector. DEVICE INTERFACE: 1 x Gigabit port (10Mbps/100Mbps/1Gbps); 1 x Gigabit PoE++ port (10Mbps/100Mbps/1Gbps); 4- pin power terminal block; LED Indicators NDAA + TAA COMPLIANT: With NDAA and TAA compliant network products, you can plan and install the networking solutions that government customers demand today. (U.S. and Canada only) POE++: Supplies power to a PoE (up to 15.4W), PoE+ (up to 30W), or PoE++ (up to 95W) device. CONNECTION DISTANCE: Connect the TI-IG90 industrial PoE injector to a non-PoE gigabit switch, and then run an Ethernet cable up to 100 meters (328 ft.) to network a PoE device. INDUSTRIAL HARDENED DESIGN: Equipped with a rugged IP50 rated housing, designed to withstand a high degree of vibration and shock, and operate within an extreme temperature range of -40° - 75° C (-40° - 167° F). DIN RAIL & WALL MOUNTS: IP50 rated industrial injector includes DIN-Rail mount and wall mount hardware POWER SUPPLY SOLD SEPARATELY: Use this industrial injector with the compatible power supply model TI-S15052 (Sold Separately) FAULT TOLERANCE: The industrial PoE++ injector features 48 - 57V DC power input with overload current protection GROUNDING POINT: The injector features a grounding point to protect equipment from external electrical surges ELECTRO MAGNETIC COMPLIANCE: Complies with industrial EMS certifications ESD (IEC 61000-4-2): Level 3 Contact: 6kV, Air: 8kV; EFT (IEC 61000-4-4): Power 2kV, Signal: 1kV; Surge (IEC 61000-4-5): Power: 2kV, Signal: 6kV More from the Manufacturer.Power supply sold separately (model: TI-S15052).NDAA / TAA compliant.Redundant power inputs with overload current protection.6kV RJ45 Ethernet surge protection

The Ubiquiti Switch Enterprise has a 124 Gb/s with 62 Gb/s non-blocking throughput and a 92.25 Mpps forwarding rate for smooth data transfers..(12) 2.5 GbE, (12) GbE; all PoE+ ports.(2) 10G SFP+ ports.400W total PoE availability.DC power backup-ready.Layer 3 switching.Remote firmware upgrade.Manage your networks from a single control panel

The Ubiquiti EdgePoint PoE injector provides a variety of features to help protect your PoE devices: surge protection, clamping protection, maximum surge discharge, peak pulse current, AC cable with earth ground..PoE injector with a variety of features to help protect your PoE devices.Compatible with airFiber, airMAX, EdgeMAX, mFi, UniFi AP, UniFi Protect, airVision, UniFi LED, UFiber.Dimensions: 1.34"H x 4.84"W x 2.56"D.Comes in white.Offers 80W of power to an Ethernet cable for PoE devices.Contains 1 x Gigabit Ethernet RJ45 LAN and 1 x PoE ports.Output voltage: 54VDC/1.5A.Rated voltage: 100-240VAC, 50/60Hz.Surge protection: difference and common Mode.Meets or exceeds the CE, FCC, IC and UL standards

Create your own LAN and connect your PC, laptop, printer and other peripherals with the help of 4 ports..Supports cost-efficient twisted pair cables for high-speed data transfer up to 100 meters.Optimize the performance of business networks with 10 Gigabit Ethernet connectivity.Layer 2 switch provides a complete lineup of features including IGMP snooping, port mirroring, and spanning tree.Managed switch provides a reliable foundation for your network

The Black Box PoE+ midspan injectors are used in Enterprise applications to power VoIP phones, wireless access points, IP security cameras and more. PoE+ injectors add power to the Ethernet link and will help you avoid upgrading non-PoE switch infrastructure. PoE enables you to avoid installing AC power at a remote powered device..Provides 30W of safe PoE Plus power to each device.Ideal for multi-radio wireless access points, PTZ security cameras, IP phones containing streaming video displays, and LCDs.Powers 802.3at and 802.3af compliant devices.Diagnostic LEDs indicate 802.3at device detection

The Ubiquiti Networks POE-50-60W PoE Adapter is a high-performance power solution designed to deliver reliable 50V, 60W output to a wide range of Ubiquiti PoE-enabled devices, including airFiber, airMAX, airVision, UniFi, and mFi series. Engineered for seamless integration into professional network environments, this adapter features a built-in Gigabit LAN port for high-speed data transmission and supports a wide input voltage range of 90–260V AC at 50/60 Hz, making it ideal for global deployments. Advanced surge protection, clamping, peak pulse current handling, and ESD shielding ensure your network stays protected against electrical threats. The compact and lightweight design (4.0 x 2.4 x 1.3 inches, 6.8 oz) allows for easy installation in tight spaces, while earth grounding support adds an extra layer of operational safety. With an operating temperature range of 32°F to 104°F (0°C to 40°C) and 35–95% humidity tolerance, the POE-50-60W is built to perform in demanding conditions. Backed by a 1-year limited warranty, this PoE adapter is the perfect choice for powering Ubiquiti devices with efficiency, safety, and speed..Powerful 50V, 60W Output: Delivers reliable Power over Ethernet (PoE) for a wide range of Ubiquiti devices including airFiber, airMAX, airVision, UniFi, and mFi series.Integrated Gigabit LAN Port: Ensures high-speed data transmission with full Gigabit Ethernet support.Advanced Surge & ESD Protection: Built-in safeguards against surge, clamping, peak pulse current, and electrostatic discharge for enhanced device safety.Wide Input Voltage Range: Operates on 90–260V AC, 50/60 Hz, making it suitable for global deployments.Earth Grounding Support: Provides additional protection and stability in professional network environments.Compact & Lightweight Design: Measures just 4.0 x 2.4 x 1.3 inches and weighs 6.8 oz for easy integration into any setup.Reliable Operating Conditions: Functions in temperatures from 32°F to 104°F (0°C to 40°C) and 35–95% humidity.IEEE 802.3af Backward Compatibility: Supports legacy PoE devices while delivering robust performance.Ideal for Ubiquiti Ecosystems: Optimized for seamless use with Ubiquiti’s networking hardware—ensuring compatibility and performance.1-Year Limited Warranty: Backed by Ubiquiti’s manufacturer warranty for peace of mind.Ubiquiti™ Networks™ 50 VDC 60 W Power over Ethernet injector provides earth grounding/surge protection and also helps to protect against ESD attacks.

As a leading provider of network equipment for businesses, NETGEAR® understands the importance of providing a great choice of PoE port counts and power budgets that can adapt to your business' needs, whether in the hospitality, catering, education or retail domains. The GS728TXPv3 and GS752TXPv3 Gigabit Ethernet Switches with PoE+ and 4 SFP+ Ports join the NETGEAR Smart switches with Cloud family, adding full 24 and 48 port PoE+ support for organizations that deploy high-density PoE+ devices and require a powerful interconnect link between access and aggregation. Organizations who buy infrastructure for the long term and want future proofing for the unforeseeable can now select a switch with a PoE power budget of 190W over 24-port, or 380W over 48-port providing more headroom. Temperature- and load-based fan-speed control combines accurate monitoring with minimized system acoustic noise: the GS728TXPv3 supports quiet rack mounting operation with a maximum of 26.80dBA even at full PoE power with traffic on all ports and 25°C (77°F) ambient. Following the same measurements, GS752TXPv3 is rated at 36.6dBA..48-Port, Gigabit, Managed Network Switch.Number of PoE+ ports (802.3at) 48, Total PoE Power budget (Watts) 380W.176 Gb/s Switching Capacity.Switch Form Factor Rack Mountable Design.Supports Up to 256 VLANs.Cloud Management and 4 SFP+ Ports.Power Draw 436.00 W (Max), 28.00 W (Idle).Effectively increases available bandwidth on your network.Quickly and easily set up a wired network with 48 networking ports.Built-in power supply to ensure all components are being supplied with accurate voltage.Supports layer 3 switching for enhanced performance and usability.Rack-mountable form factor allows hassle-free and easy usage with increased efficiency
