Mini GBIC Transceivers

The Opengear 1000Base-LX/LH mini-GBIC SFP transceiver module operates at 1 Gbps and offers optical links up to 10 km long via single-mode fiber cable at a wavelength of 1310 nm. It is compatible with IM7200 infrastructure manager for data networking..SFP transceiver module for data networking, optical network and compatible with IM7200 infrastructure manager.Interfaces/ports: One 1000Base-LX/LH network.Ethernet technology: Gigabit Ethernet, Maximum data transfer rate: 1 Gbps, Max transfer distance: 10 km, Optical wave length: 1310 nm.Media type supported: Optical fiber, Fiber mode supported: Single-mode

It installs in a Mini-GBIC compliant slot and features a duplex LC connector that is compatible with 850nm multi-mode fiber cables..Type of Product/Use: Transceiver.Dimensions/Size: 2.2 x 0.5 x 0.3 inch.True color: Silver.850nm Wavelength for Multi-Mode Fiber.Connectivity media: 62.5/125 microm multi-mode optical fiber, 50/125 microm multi-mode optical fiber.Max transfer distance: 721.78 ft 62.5/125 microm, 902.23 ft 62.5/125 microm, 1640.42 ft 50/125 microm, 1804.46 ft 50/125 microm optical fiber.Data transfer rate: 1 Gbps gigabit-ethernet.Transmitter spec: Power: -9.5 to -4 dBm, Receiver spec: sensitivity: -20 to -17dBm, Input power: -20 to -17 dBm.Stress sensitivity: 50/125 um: -13.5 dBm, 62.5/125 um: -12.5 dBm, Wavelength: 850 nm (850nm TYP., 830-860nm) MMF.Environmental condition: Operating temperature: 32 - 104 deg F, Storage temperature: -4 -158 deg F Operating humidity: 0% to 85% non-condensing.Modular bandwidth for MMF: 62.5/125um MMF at 160 MHz/km, up to 220m, 62.5/125um MMF at 200 MHz/km, up to 275m, 50/125um MMF at 400 MHz/km, up to 500m, 50/125um MMF at 500 MHz/km, up to 550m.Provides a simple way to add Gigabit functionality to your Linksys switch.Gigabit fiber is often-used to connect two switches together.Technology used depends on the distance between the two switches.SX module uses 850 nanometer wavelength light in multimode fiber-optic cables, and can achieve distances up to 220 or 550 meters, depending on the fiber used.The Gigabit Ethernet SX Mini-GBIC SFP Transceiver from Cisco is an expansion module that adds high-density fiber connectivity to compatible devices.

It installs in a Mini-GBIC compliant slot and features a duplex LC connector that is compatible with 850nm multi-mode fiber cables..Type of Product/Use: Transceiver.Dimensions/Size: 2.2 x 0.5 x 0.3 inch.True color: Silver.850nm Wavelength for Multi-Mode Fiber.The Gigabit Ethernet SX Mini-GBIC SFP Transceiver from Cisco is an expansion module that adds high-density fiber connectivity to compatible devices.

Cisco 1000BASE-LX SFP (mini-GBIC) Transceiver easy-to-install module that provide a simple way to add fiber connectivity or to add an extra Gigabit Ethernet port to your Cisco Small Business or Cisco Small Business Pro Series switches. The transceiver available for single-mode fiber-optic cabling and can support distance up to 10 kilometers..Type of Product/Use: Transceiver.Dimensions/Size: 0.5 x 0.3 x 2.2 inch.True color: Silver.1000Base-LX.1 x LC Duplex Connector.Single-Mode Fiber (SMF).10 km (6.2 miles) Max..1000 Mbps Transfer Rate.The MGBLX1 SFP Transceiver from Cisco is an easy-to-install module that provides a simple way to add an extra Gigabit Ethernet port to your Cisco Small Business or Cisco Small Business Pro Series switches.

Industry standard Cisco small form factor pluggable (SFP) gigabit interface converter is a hot-swappable input/output device that plugs into a gigabit Ethernet port or slot, linking the port with the network..Interfaces/ports: 1 x LC duplex 1000Base-LX/LH.Dimensions: 0.3"(H) x 1/2"(W) x 2.2"(D).Compatibility: Cisco IE 3000 series switches, cisco 3200 series rugged routers, cisco MWR 2900 mobile wireless routers.Connectivity technology: Wired.Connectivity media: Single mode fiber 1000Base-LX/LH.Operating temperature: -40 - 185 deg F.Fiber type: SMF/MMF.Cabling type: Ethernet 1000Base-LX.Additional information: Spare product, range: 10 Km, wavelength: 1300 nm.Data transfer rate: 1 Gb/s gigabit Ethernet.Form factor: Hot swappable/plug-in.Application/usage: Data networking.SFP (mini-GBIC) transceiver module 1000 MBPS SFP single mode rugged 1000BASE-LX/LH SFP for MMF and SMF.

The StarTech.com® GLCTST hot-pluggable SFP transceiver ensures a reliable GbE connection up to 100 m using RJ-45 connector. This transceiver offers port flexibility to match your changing needs over time, from copper to fiber..Hot-pluggable transceiver provides reliable and cost effective GbE connection using RJ-45 connector.Dimensions: 0.6"H x 0.5"W x 2.7"D.Comes in silver color with aluminum enclosure.Interfaces/port: 1 x RJ-45 female.Ethernet technology: Gigabit Ethernet.Media type supported: Twisted pair.Maximum data transfer rate: 1 Gbps.Operating range: 100 m.Compatible with Mini-GBIC fiber (MM or SM) and copper (RJ45) slots (NICS, fiber media converters).Ideal for use in switches, routers and other networking equipment, SFP allows to expand your network to remote segments cost-effectively.It provides a versatile and convenient solution that is compatible with a multitude of multi and single-port Gigabit Ethernet networking devices.Meets RoHS, WEEE standards.Weight: 0.9 oz..Comes with lifetime warranty

The NETGEAR AGM731F fiber 1000BASE-SX SFP GBIC module expands the capabilities of your existing switch, enabling it to accept fiber-optic connections. The module is compact in size and plugs in easily, so you can upgrade your system in less than a minute. It features a single port, so you can extend network coverage across a larger area..Interfaces/ports: 1 x LC 1000Base-SX LAN.Dimensions: 0.4"(H) x 1/2"(W) x 2.6"(D).Compatibility: Adds fiber optic connectivity to the GSM7324, meets SFP GBIC standard for use with any SFP GBIC compliant slot 1000BASE-SX connectivity.Connectivity technology: Wired.Connectivity media: 62.5 um multi mode fiber 1000Base-SX, 50 um 1000Base-SX.Operating temperature: 32 - 104 deg F.Humidity: 10 - 90%.MTBF: 5,083,574 hours.Module support: Mini-GBIC, SFP.Data transfer rate: 1 Gb/s.Performance class: Gigabit ethernet.Form factor: Plug-in module.Application/usage: Data networking.Expansion slots: 4 (total)/4 (free) x SFP (mini-GBIC).5 years limited warranty.NETGEAR AGM731F Fiber 1000BASE-SX SFP GBIC Module - High-Speed Connections

The Allied Telesis™ AT-SPSX-90 SFP (mini-GBIC) module is perfect for data networking and optical network. This multi-mode module with SX network works based on 1000Base-SX Gigabit Ethernet technology. The hot-swappable module supports a maximum distance of 1804.46' and maximum data transfer rate of 1.25 Gbps. It has 1 x LC 1000Base-SX network interface for external connections. This module supports 62.5/125 mu m and 50/125 mu m optic fiber..Hot-pluggable SFP (miniGBIC) module is perfect for data networking.Connectors: 1 x LC.Ethernet technology: Gigabit Ethernet.Network technology: 1000Base-SX.Data transfer rate: 1 Gbps.Media type: 62.5/125 mu m, 50/125 mu m multi-mode optical fiber.Maximum reach: 220m/550m.Wavelength: 850 nm.Meets Eco, RoHS, WEEE, REACH standards

Supports twisted pair cables for durability and improved signal transfer while ensuring smooth and seamless data transfer.Gigabit Ethernet port for ultra-fast network speeds.With 10/100/1000Base-TX technology, get up to 1000Mbps data transfer rate over twisted pair cable

The Dell™ 407-BBOS 220 m RJ-45 1000Base-T Gigabit Ethernet SFP transceiver module is compatible with Dell networking N3024, N3024F and N3024P switches. Plug-in transceiver module with Gigabit Ethernet technology, transmits data at the rate of 1.25 Gbps..Transceiver module for data networking.Form type: SFP (mini-GBIC).Interfaces/ports: One RJ-45 1000Base-T Ethernet network.Reach: 220 m.Ethernet technology: Gigabit Ethernet.Compatibility: Dell networking N3024, N3024F, N3024P.Form Factor: Plug-in module.Data transfer rate: 1.25 Gbps.Operating temperature rating: 85 deg C

The Transition Networks M/GE-ISW series is a hardened Gigabit Ethernet mini media converter that provides cost-effective media conversion between 10/100/1000Base-T RJ-45 port and 100/1000Base-X open SFP slot for hardened or outdoor environments. With its supported operating temperature range of -40 degree Celcius to +75 degree Celcius, the mini converter offers a space-saving alternative for converting copper to fiber in extreme environments..Mini Gigabit Ethernet media converter provides simple and cost-effective integration of copper and fiber equipment.Dimensions: 0.85"H x 1.8"W x 3.3"D.Comes in black.Interfaces: 1 x RJ-45 10/100/1000Base-T, 1 x SFP 100/1000Base-X.Features auto MDI/MDIX, copper and fiber auto-negotiation.Supports fixed full-duplex operation on the fiber port.Offers jumbo frame (up to 10240 bytes) support and active link pass-through for reliable data transfer.Unit and port LEDs allow for quick status information.Supports DC and AC input power via terminal block.Provides overload current and reverse polarity protection.Can be mounted with an included DIN rail clip and Velcro or wall mount bracket (sold separately).Meets or exceeds FCC Class A standard.Lifetime manufacturer limited warranty

Supports optical fiber cable for durable performance, minimal signal loss, and fast data transfers to greater distances.With a single wavelength of light, the single mode fiber optic can carry data and transmit audio/video applications over miles of distance.Gigabit Ethernet port for ultra-fast network speeds.With 1000Base-LX technology, enjoy up to 1000Mbps data transfer rate over optical fiber cable

Dell™ Sonicwall® 1000Base-SX SFP Short haul transceiver module eliminates potential points of failure associated with separate multiple vendor solutions. Module has SFP mini-GBIC compatible slots and supports wired connectivity technology..Interfaces/ports: 1 x Ethernet 1000Base-SX network.Media & performance: Connectivity media: Optical Fiber 1000Base-SX, Data Transfer rate: 1 Gb/s.Ethernet technology: Gigabit Ethernet.For SuperMassive E10000 Series, SuperMassive 9000 Series.Application/usage: Data Networking, optical network.Form factor: SFP.Warranty: 1 year limited.Dell™ Sonicwall® 1000Base-SX SFP Mini-GBIC short haul transceiver module is used in data networking as well as optical network and has a data transfer rate of 1 Gb/s.

The Dell™ 407-BBOR SFP mini-GBIC network transceiver is perfect for data networking and optical network applications. It features one LC duplex 1000Base-SX network interface and supports Gigabit Ethernet technology for high-speed data transmission. This network transceiver transmits data at a rate of 1 Gbps. It offers data transmission over multi mode optical fiber media up to a range of 550 m at 850 nm wavelength. This transceiver is compatible with Dell Networking N2048, N4000, N4032F, N4064F, N2024P switches, Dell PowerConnect 2848, 5524P, 5548p, 6224F, 6248P and 7024F switches..SFP network transceiver for data networking and optical network applications.Interfaces/ports: One LC duplex 1000Base-SX network.Data transfer rate: 1 Gbps.Ethernet technology: Gigabit Ethernet.Wavelength: 850 nm.Media type supported: Multi-mode optical fiber.Compatibility: Dell Networking N2048, N4000, N4032F, N4064F, N2024P switches, Dell PowerConnect 2848, 5524P, 5548p, 6224F, 6248P, 7024F switches.Max transfer distance: 550 m

The StarTech® J4858C10PKST SFP (mini-GBIC) transceiver module supports half/full duplex multi mode fiber optic network connectivity. The transceiver module transfers the data over MMF at 1.25-Gbps speed, with a maximum reach up to 550 m at a wavelength of 850 nm using LC connector. This hot pluggable transceiver module provides highly reliable and cost-effective GbE network connections for 1000Base-SX networks and supports digital diagnostic monitoring..100% compatibility with HP J4858C guaranteed.StarTech® SFP modules are backed by a lifetime warranty.Meets or exceeds OEM specifications and Multi-Source Agreement (MSA) industry standards.Low power consumption of less than 1 W.Hot-swappable with fiber-optic modules.SFP network transceiver module is ideal for large-scale deployments or installations on multiple devices, this bulk pack of HP compatible gigabit fiber SFPs.
